Omron XS3W-M424-401-PR Extension Cable Technical Guide
| Feature | Value |
|---|---|
| Product Type | Extension Cable |
| Series | Omron XS3 Water-resistant Connectors |
| Connector 1 | M8 Straight Socket (Female) |
| Connector 2 | M8 Straight Plug (Male) |
| Number of Contacts | 4 |
| Cable Length | 1 m |
| Cable Material | PUR Oil-resistant Robot Cable |
| Protection Rating | IP67 |
| Connector Nut Material | Brass |
| Cable Color | Black |
| Application | Industrial Sensor Extension |
The Omron XS3W-M424-401-PR Extension Cable is a factory-assembled M8 extension cable developed for industrial automation systems that require reliable and standardized sensor connectivity. This model features a straight female M8 socket on one end and a straight male M8 plug on the other, making it suitable for installations where direct cable routing is preferred. According to the manufacturer’s specifications, the cable incorporates four contacts, a one-meter PUR oil-resistant robotic cable, and an IP67-rated sealing structure designed for demanding industrial environments.
Technical Description
The Omron XS3W-M424-401-PR Extension Cable is part of the XS3 connector family used throughout factory automation applications. The cable is supplied with molded connectors that eliminate field assembly while helping maintain consistent electrical performance. The straight connector configuration is particularly suitable for installations where sufficient clearance exists behind connected equipment.
The PUR cable jacket provides durability in environments where mechanical movement, vibration, and exposure to industrial oils are expected. The Omron XS3W-M424-401-PR Extension Cable is intended to extend compatible four-pin M8 connections without changing electrical characteristics or communication signals.
Operating Principle
This extension cable functions as a passive electrical link between compatible M8 devices. Power supply conductors and signal lines are transferred through four internal conductors while preserving the original wiring arrangement. Because the cable contains no active electronic components, signal quality depends on proper installation and compatible equipment.
When both connectors are correctly tightened, the sealing system provides IP67 protection against dust ingress and temporary water exposure in accordance with the manufacturer’s published specifications.
Typical Applications
- Industrial proximity sensors
- Photoelectric sensor installations
- Factory automation systems
- Distributed I/O networks
- Packaging machinery
- Machine tools
- Material handling equipment
- Automated assembly systems
Industrial Applications
The straight connector arrangement makes this cable suitable for installations where devices are mounted with sufficient rear clearance and cable routing follows linear paths. It is frequently used to extend sensor connections between field devices and control equipment while maintaining standardized M8 interfaces.
Machine builders, system integrators, and maintenance engineers often use standardized extension cables to simplify replacement procedures and reduce installation complexity. The PUR robotic cable is also appropriate for equipment subjected to repeated mechanical movement.
Advantages
- Factory-assembled cable with molded connectors.
- Straight connector configuration for direct cable routing.
- Oil-resistant PUR cable jacket.
- Designed for robotic and industrial applications.
- Four-pin M8 standardized interface.
- Compact one-meter cable length.
- IP67 protection when properly connected.
- Brass coupling nuts ensure secure mechanical fastening.
Industry Examples
Assembly Automation
Production equipment uses standardized M8 extension cables to connect sensors positioned near assembly fixtures and indexing mechanisms.
Machine Manufacturing
Machine builders can simplify installation by extending sensor wiring using factory-assembled cable assemblies instead of custom wiring solutions.
Omron XS3W-M424-401-PR Conveyor Systems
Sensors installed along conveyor sections can be connected to distributed I/O modules while maintaining organized cable management.
Electronics Production
Compact automation equipment benefits from standardized sensor wiring that simplifies maintenance and future equipment modifications.
Omron XS3W-M424-401-PR Selection Considerations
When selecting an extension cable, confirm the required connector orientation, cable length, and contact configuration. The one-meter cable is suitable for localized extensions where excess cable should be minimized. Verify compatibility with four-pin M8 devices and ensure installation follows the manufacturer’s recommended environmental conditions.
For compatible connection accessories and industrial sensing products, explore additional Omron sensor solutions suitable for automation applications.
Frequently Asked Questions
1. What connector configuration does this cable use?
It features one M8 straight female socket and one M8 straight male plug.
2. How many contacts are included?
The cable provides four electrical contacts.
3. What is the cable length?
The overall cable length is 1 meter.
4. Is the cable designed for industrial environments?
Yes. It is intended for industrial automation applications and incorporates an oil-resistant PUR cable.
5. What protection rating is provided?
When correctly connected, the cable assembly meets the IP67 protection rating.
6. Can it be used with industrial sensors?
Yes. It is designed to extend compatible four-pin M8 sensor connections.
7. Does the cable require field wiring?
No. The connectors are factory assembled, allowing immediate installation.
8. Why choose straight connectors?
Straight connectors are appropriate when installation space allows direct cable routing and minimal cable bending is required.
