Omron S8VK-WB48048 480W 48VDC 10A Three-Phase Power Supply
The Omron S8VK-WB48048 is an industrial switch mode power supply developed to deliver stable 48 VDC power in machine automation, control panels and production systems. Offering a rated output of 480 W and 10 A, it is suitable for applications requiring high output capacity, efficient operation and dependable power distribution. Customers can contact Emaconn to request current pricing, availability, delivery information and product selection support.
Reliable Power for Industrial Control Systems
Automation equipment requires consistent DC power to maintain the reliable operation of controllers, communication devices, relays, sensors and other electronic components. This model supports both three-phase and two-phase AC input, making it suitable for various industrial electrical infrastructures.
Its wide input range of 320 to 576 VAC enables use with nominal 380 to 480 VAC industrial networks. A 450 to 810 VDC input range is also supported, subject to Omron’s installation instructions and the electrical requirements of the application.
Omron S8VK-WB48048 Technical Specifications
| Product series | S8VK-WB |
|---|---|
| Rated output power | 480 W |
| Output voltage | 48 VDC |
| Rated output current | 10 A |
| Power Boost current | 15 A |
| Input voltage range | 320–576 VAC or 450–810 VDC |
| Input frequency | 47–63 Hz |
| Voltage adjustment range | 48–56 VDC |
| Typical efficiency | 94% at three-phase 400 VAC input |
| Operating temperature | -40°C to +70°C with applicable derating |
| Protection rating | IP20 |
| Installation | DIN rail mounting |
Power Boost and Monitoring Functions
The Power Boost function can provide up to 15 A for temporary load requirements when the specified operating conditions are satisfied. This capability is useful for equipment with brief current peaks during start-up or normal machine cycles.
INPUT OK, DC OK and Iout > 100% indicators allow operating conditions to be checked directly from the control cabinet. DC OK and excessive-current signal outputs can also be integrated into monitoring systems. Automatic overload protection and overvoltage protection help protect the power supply and connected equipment during abnormal conditions.
Push-In Plus Terminal Technology
Push-In Plus terminals support fast and secure wiring, reducing installation effort during panel assembly and maintenance. Combined with its compact DIN rail construction and fanless design, the unit can help panel manufacturers create organised and service-friendly electrical cabinets.
Typical Applications
- Industrial automation cabinets
- PLC and motion control systems
- Robotic production cells
- Packaging and material-handling machinery
- Process control installations
- Industrial communication equipment
- OEM machines and electrical panels
Omron S8VK-WB48048 Product Selection and Ordering
Before purchasing, verify the available input voltage, total continuous load, temporary peak-current requirements, ambient temperature and cabinet space. Additional capacity should be considered where future system expansion is expected.
Contact Emaconn to confirm current stock status, commercial terms, delivery options and compatibility before ordering. More information about related products is available on the Omron product page.
Omron S8VK-WB48048 Frequently Asked Questions
What output does this model provide?
It supplies 48 VDC with a rated output current of 10 A and a total rated power of 480 W.
Does it support temporary current peaks?
Yes. The Power Boost function supports up to 15 A under the operating conditions specified by Omron.
How can customers request a quotation?
Customers can contact Emaconn with the complete product code to request current pricing, availability and delivery information.
