Omron S8FS-G01505CD 15 W 5 VDC DIN Rail Power Supply
The Omron S8FS-G01505CD power supply is an enclosed switch mode unit designed to provide a regulated 5 VDC output for compatible industrial control devices. It delivers 15 W of power with a rated output current of 3 A and supports DIN rail installation inside control cabinets. Machine builders, system integrators, maintenance departments, and industrial procurement teams can contact Emaconn for current pricing, stock availability, delivery information, and product selection support.
Compact 5 VDC Power for Control Equipment
Industrial installations sometimes include electronic devices that require a lower supply voltage than the commonly used 24 VDC control standard. The S8FS-G01505CD addresses this requirement by converting a broad AC or DC input into a 5 VDC output. Suitable loads may include compatible electronic control boards, interface circuits, communication equipment, indicators, and specialised machine components.
The rated 3 A output must be compared with the continuous and peak demand of the connected equipment. Starting currents, simultaneous device activation, cable voltage drop, and future expansion should be included in the calculation. Operating the unit with an appropriate capacity margin can support more stable system performance and practical thermal management.
Confirmed Technical Characteristics
- Product type: Enclosed switch mode power supply
- Rated output power: 15 W
- Output voltage: 5 VDC
- Rated output current: 3 A
- Rated AC input: 100 to 240 VAC
- Allowable AC input range: 85 to 264 VAC
- Allowable DC input range: 80 to 370 VDC
- Efficiency: 80%
- Operating temperature range: -20°C to 70°C
- Mounting method: DIN rail
- Terminal type: Front-facing screw terminals
- Output branches: One
- Dimensions: 82 mm wide, 35 mm high, and 99 mm deep
These specifications are published on the official Omron S8FS-G01505CD product page. The latest manufacturer datasheet should also be reviewed for detailed derating curves, protective functions, installation clearances, standards, and safety instructions.
Where the S8FS-G01505CD Can Be Used
The product can be considered for automation cabinets, packaging machinery, inspection stations, production monitoring systems, and OEM equipment containing compatible 5 VDC loads. Its compact dimensions can be useful when available rail and cabinet space are limited. However, the physical layout must still provide sufficient access for wiring, ventilation, testing, and future replacement.
DIN rail mounting supports organised panel construction and can simplify installation alongside terminal blocks, relays, controllers, and interface components. Front-facing screw terminals provide accessible connection points for technicians. Correct conductor preparation and terminal tightening remain important because poor electrical connections may create voltage instability or unwanted heat.
Essential Selection Criteria
The first requirement is to verify that every intended load is designed for a 5 VDC supply. A 5 V model must not be selected as a replacement for a 12 VDC or 24 VDC power supply solely because the mechanical format appears similar. Output voltage, rated current, input range, mounting design, dimensions, and terminal arrangement should all match the application.
Engineers should calculate the total current demand and confirm that it remains safely within the 3 A rating under normal and peak conditions. Long conductors can cause a meaningful voltage drop in low-voltage systems, so cable length and conductor cross-section deserve particular attention. Voltage should be checked at the load during commissioning rather than only at the power supply terminals.
The published operating temperature range extends from -20°C to 70°C, but maximum output availability may depend on ambient temperature, mounting orientation, input voltage, and ventilation. The relevant derating information must therefore be evaluated when the unit is installed in a warm or densely populated enclosure.
This model has no communication port or integrated alarm function. Applications requiring remote diagnostics, status signalling, redundancy, or network monitoring may need additional external devices or another power supply model. These functional requirements should be identified before requesting a quotation.
Installation and Preventive Maintenance
Installation should be performed by qualified personnel in accordance with the current Omron instructions and applicable electrical regulations. The supply circuit should include suitable protection, and the unit must be correctly grounded. Power and signal conductors should be routed carefully to reduce interference and accidental wiring damage.
Before energising the system, technicians should verify input voltage, output polarity, conductor size, terminal security, and the expected load. Routine inspections may include checking screw terminals, ventilation spaces, dust accumulation, discolouration, unusual noise, and excessive temperature. Electrical power must be isolated safely before maintenance work begins.
Purchasing Support from Emaconn
Emaconn can assist B2B customers with price requests, availability checks, estimated lead times, international sourcing, and project-based quotations for the S8FS-G01505CD. Buyers can provide the exact part number, required quantity, delivery country, and planned order date to receive more relevant commercial information.
Support can also include part-number verification and comparison with alternative power supply models when the required voltage, current, mounting arrangement, or functionality differs. Explore the Omron industrial automation products available through Emaconn for related components and sourcing assistance. Electrical and mechanical compatibility should be confirmed before the purchase order is finalised.
Conclusion
The Omron S8FS-G01505CD power supply provides a compact 15 W solution for industrial equipment requiring 5 VDC at up to 3 A. Its DIN rail format, wide input capability, enclosed construction, and accessible screw terminals support organised control-panel integration. Final selection should consider load current, cable voltage drop, temperature derating, cabinet dimensions, and the absence of communication or alarm functions. Contact Emaconn to request current pricing, check availability, discuss an alternative model, or obtain a project quotation.
Frequently Asked Questions
What output does the Omron S8FS-G01505CD provide?
It provides a rated 5 VDC output, 3 A current capacity, and 15 W power output.
Is this model designed for DIN rail installation?
Yes. The product is configured for DIN rail mounting inside compatible industrial control enclosures.
Which input voltages can it accept?
The allowable range is 85 to 264 VAC or 80 to 370 VDC, subject to the manufacturer’s installation requirements.
Can it replace a 24 VDC power supply?
No. It is a 5 VDC model and should only supply equipment designed to operate at that voltage.
How much current can be connected?
The rated output current is 3 A. The total continuous and peak load should remain within the permitted operating limits.
Does it include a communication port?
No communication interface is specified for this model.
What should be checked before commissioning?
Confirm the input supply, output polarity, connected load, conductor size, terminal tightness, grounding, and ventilation.
How can the current price be requested?
Submit the exact model number, required quantity, destination, and commercial requirements for an up-to-date quotation.
Can availability and lead time be checked?
Yes. Stock status and estimated lead time can be confirmed during the enquiry because supply conditions may change.
Are project and bulk-order quotations available?
Quantity-based requirements can be assessed according to volume, delivery location, documentation, and project schedule.
Can a different Omron model be recommended?
Alternative models can be evaluated when the application requires another voltage, current rating, mounting style, or monitoring function.
