Omron G2RV-SR500-AP 110VAC Relay Socket Overview

The Omron G2RV-SR500-AP 110VAC relay socket is a slim industrial interface relay developed for control panels that require reliable switching of small electrical signals. It combines an electromechanical relay and low-profile socket structure in a narrow 6.2 mm body, helping panel builders organize dense wiring layouts more efficiently.

Technical Profile

This model uses a 110VAC rated input voltage. Its rated current is approximately 5.9 mA at 50 Hz and 5.9 mA at 60 Hz, with power consumption around 0.8 VA. As an AP micro-load model, it features Ag alloy contacts with Au plating. This makes it particularly relevant for low-current circuits where stable contact performance matters.

Application Areas

The Omron G2RV-SR500-AP 110VAC relay socket is suitable for industrial automation panels, machine control wiring, alarm circuits, signal conversion, and PLC input/output separation. It is especially practical in systems where 110VAC control voltage is already standardized across the panel architecture.

Practical Advantages

The Push-In Plus terminal design reduces wiring effort and helps maintain consistent terminal pressure. Its mechanical structure also supports easier replacement, because the relay portion is built for plug-in handling. For technicians, the transparent case and LED operation display simplify basic diagnostics during commissioning and service.

For broader Omron automation references, see Omron relay and control components.

FAQ

What makes the 110VAC version different from the 100VAC version?

The core relay structure is similar, but the input circuit is rated for 110VAC. This matters when matching the relay to the control voltage available in the panel.

Is the Omron G2RV-SR500-AP 110VAC relay socket designed for micro-loads?

Yes. The AP suffix identifies the micro-load contact version, supported by gold-plated contact material.

Can it be installed in compact panels?

Yes. Its slim 6.2 mm width is one of the key reasons engineers choose it for space-sensitive DIN rail layouts.

Does it help with troubleshooting?

Yes. The operation indicator and transparent case provide quick visual feedback during inspection.
