Weidmüller 1007900000 ZP 2.5/1AN/QV Plug Connector Guide
The Weidmüller 1007900000 ZP 2.5/1AN/QV plug connector is a Z-series terminal block accessory designed for direct mounting and fast additional assembly in industrial cabinets. In practical panel-building environments, connectors like this are valued because they help speed up installation without losing the structure and reliability expected in professional terminal systems. The Weidmüller ZP 2.5/1AN/QV plug connector fits exactly into that requirement.
This product is described as a plug for the additional assembly of terminal blocks and is intended to be quick and easy to plug in. It is a 1-pole version in the 2.5 mm² class, built for direct mounting and aligned with IEC 60947-7-1. Published technical data lists conductor acceptance from 0.13 mm² to 4 mm², AWG 26 to 12, a 10 mm stripping length, 500 V rated voltage, 24 A nominal current, and a TS 35 offset of 31 mm.
What Makes the 1007900000 Useful
The Weidmüller 1007900000 connector is designed for users who need a compact and dependable plug-in solution within terminal block assemblies. A single-pole format can be particularly useful in selective circuit organization, modular cabinet design, and configurations where only one connection path is required per accessory position.
In daily practice, a 1-pole terminal accessory is often chosen for clarity, flexibility, and controlled routing rather than sheer connection density. It allows designers to build up a system with more granularity, which can help both assembly and troubleshooting.
Technical Characteristics
The published conductor range of 0.13 mm² to 4 mm² means the connector can accommodate a wide variety of common industrial conductors. The support for AWG 26 to 12 adds further relevance in international design and service contexts. A 10 mm stripping length and top connection direction also make the connector easy to integrate into routine cabinet production workflows.
Electrically, the Weidmüller ZP 2.5/1AN/QV is aligned with a 2.5 mm² rated cross-section, 500 V rated voltage, and 24 A nominal current. The cCSAus and cURus data also show 20 A / 300 V for size C and 5 A / 600 V for size D, which helps engineers working with multiple approval frameworks.
Material and Standards Context
The connector family is referenced to IEC 60947-7-1, which is central in terminal block evaluation. The family also uses Wemid insulation material and UL 94 V-0 flammability classification in comparable ZP 2.5 variants. These details matter because terminal accessories are selected not only by current and voltage, but also by long-term material behavior and compliance expectations.
In industrial design, it is often the combination of standards, conductor range, and installation simplicity that determines whether a terminal accessory becomes a practical choice. The Weidmüller 1007900000 plug connector checks all of those boxes.
Application Areas
This connector is relevant in control cabinets, machine-building projects, industrial retrofit work, and structured terminal expansions where single-pole flexibility is an advantage. It is especially useful where terminal assembly must remain modular and service-friendly over time.
Weidmüller 1007900000 For more information about Weidmüller, it is worth comparing 1-pole and 2-pole Z-series accessory options within the same terminal platform.
Weidmüller 1007900000 FAQ
What is the Weidmüller 1007900000 ZP 2.5/1AN/QV?
It is a 1-pole Z-series plug-in connector for the additional assembly of terminal blocks, designed for direct mounting.
What conductor sizes does it support?
The product page lists a conductor range from 0.13 mm² to 4 mm², covering many common industrial wiring applications.
What are the key electrical ratings?
The connector is associated with a 2.5 mm² rated cross-section, 500 V rated voltage, and 24 A nominal current, along with supplementary cCSAus and cURus approval values.
How many poles does this connector have?
The Weidmüller 1007900000 is a single-pole connector, which makes it useful where selective or modular wiring is preferred.
What standard is it designed in accordance with?
The product data references IEC 60947-7-1, a major standard for terminal block related components.
Why is a 1-pole plug-in connector useful?
It allows more flexible terminal configuration, clearer circuit organization, and easier adaptation in cabinets where individual connection points need to remain modular.
