Omron XS3W-M42C-4C2-A Connector Cable Technical Guide

The Omron XS3W-M42C-4C2-A Connector Cable is designed to interconnect industrial devices that use M8 and M12 connector interfaces. It combines a straight M8 female socket with a straight M12 Smartclick male plug through a factory-assembled 0.2-meter PVC cable. This compact cable assembly simplifies the integration of compatible sensors and automation devices while maintaining reliable electrical performance and environmental protection. The IP67-rated construction allows the cable to be used in industrial environments where dust and temporary exposure to water are common operating conditions. :contentReference[oaicite:0]{index=0}

Technical Description

The Omron XS3W-M42C-4C2-A Connector Cable belongs to the XS3 series of industrial waterproof connector assemblies. It provides four electrical contacts for signal and power transmission between compatible automation components. The cable is factory molded to ensure consistent electrical characteristics and eliminate field assembly errors.

The Smartclick M12 connector reduces installation time by allowing quick connection while maintaining secure mechanical locking. The PVC cable offers flexibility for standard industrial installations and supports organized cable routing inside automation equipment.

Working Principle

The cable operates as a passive interconnection assembly. Electrical signals and supply voltage are transferred directly through four individually insulated conductors between the M8 female connector and the M12 male connector.

Both connector interfaces include sealing elements that maintain the IP67 protection rating when properly connected to compatible mating connectors. This construction helps protect electrical contacts from contaminants while ensuring stable communication between connected devices.

Typical Applications

• Industrial sensor integration
• IO-Link device connections
• Factory automation systems
• Compact machine installations
• Control cabinet interfaces
• Machine builder standard wiring
• Sensor-to-master communication
• Automation retrofit projects

The Omron XS3W-M42C-4C2-A Connector Cable is especially useful when M8 field devices must be connected directly to equipment using an M12 interface without custom cable fabrication.

Industrial Applications

Automation engineers frequently use connector conversion cables to simplify equipment installation while maintaining standardized wiring practices. In electronics manufacturing, compact inspection sensors often communicate through M8 interfaces while control equipment uses M12 connections.

Packaging machines, material handling equipment, conveyor systems, and assembly stations also benefit from short connector conversion cables that reduce unnecessary cable loops inside machine enclosures. The compact 0.2-meter length is suitable for installations where connected devices are positioned close together.

Advantages

• Factory-assembled cable construction
• M8 to M12 interface conversion
• Four-pin industrial wiring configuration
• Compact 0.2-meter cable length
• Smartclick M12 connector design
• IP67 environmental protection
• PVC cable suitable for industrial applications
• Reduces field wiring requirements

Omron XS3W-M42C-4C2-A Industry Examples

Machine Building

OEM manufacturers use short connector cables to connect decentralized sensors to modular machine sections while maintaining standardized interfaces.

Packaging Automation

Compact sensor installations benefit from direct M8-to-M12 connectivity without requiring additional extension cables.

Electronics Manufacturing

Inspection equipment often combines multiple connector standards, making interface conversion cables practical for modular system layouts.

Material Handling

Conveyor-mounted sensing devices can be connected to nearby IO-Link or automation components using short factory-assembled cable assemblies.

Considerations When Selecting the Product

• Verify compatibility between M8 and M12 connector interfaces.
• Confirm that four contacts meet application requirements.
• Ensure the 0.2-meter cable length is appropriate for the installation.
• Check Smartclick M12 compatibility with connected equipment.
• Verify environmental requirements are compatible with IP67 protection.
• Inspect connector sealing surfaces before installation.

Additional Omron sensor products are available for applications requiring alternative connector combinations, cable lengths, or cable materials.

Omron XS3W-M42C-4C2-A Frequently Asked Questions

What is the main purpose of this cable?

It provides a direct connection between compatible M8 and M12 industrial devices using a factory-assembled cable.

Which connector types are included?

The cable uses an M8 straight female socket and an M12 Smartclick straight male plug.

How many electrical contacts are available?

The connector cable provides four electrical contacts.

What is the cable length?

The overall cable length is 0.2 meters.

Is the cable suitable for industrial environments?

Yes. When correctly installed, it provides IP67 protection against dust and temporary water exposure.

What cable material is used?

The assembly uses a standard industrial PVC cable.

Can it be used with IO-Link equipment?

It can be used wherever the connector configuration and electrical characteristics match the connected IO-Link or automation devices.

Where is the Omron XS3W-M42C-4C2-A Connector Cable commonly installed?

The Omron XS3W-M42C-4C2-A Connector Cable is commonly used in factory automation systems, machine building, packaging equipment, conveyor installations, industrial sensor networks, and control systems where an M8 field connection must interface with an M12 connector.
