Omron XS3W-M422-401-PR Extension Cable
| Feature | Value |
|---|---|
| Product Type | M8 Extension Cable |
| Manufacturer | Omron |
| Connector 1 | M8 Right-Angle Female |
| Connector 2 | M8 Straight Male |
| Number of Contacts | 4 |
| Cable Length | 1 m |
| Cable Jacket | PUR Oil-Resistant Robot Cable |
| Rated Voltage | 125 VDC |
| Rated Current | 1 A |
| Protection Rating | IP67 |
| Operating Temperature | 0°C to +70°C |
| Outer Diameter | Ø4 mm |
| Contact Resistance | 40 mΩ max. |
| Insulation Resistance | 1000 MΩ min. at 500 VDC |
| Dielectric Strength | 1000 VAC for 1 minute |
Space constraints are common in modern industrial equipment, particularly where compact sensors are installed near moving machine components or protective guarding. The Omron XS3W-M422-401-PR Extension Cable addresses these installation challenges by combining a right-angle M8 female connector with a straight M8 male connector in a factory-assembled cable designed for industrial automation.
The Omron XS3W-M422-401-PR Extension Cable incorporates a PUR oil-resistant robot cable that supports applications involving repeated movement, cable carriers, and exposure to industrial lubricants. Its molded connector construction minimizes installation time while maintaining consistent sealing performance.
Omron XS3W-M422-401-PR Technical Description
This extension cable belongs to Omron’s XS3 waterproof connector family. It features four electrical contacts using the standard M8 interface widely employed for industrial sensors and compact automation devices. The right-angle female connector allows cable routing where straight connectors would require additional clearance.
The PUR cable jacket offers improved resistance to oils, abrasion, and repeated flexing, making the assembly suitable for demanding industrial environments where long-term cable durability is important.
Working Principle
The extension cable transfers electrical power and sensor signals through four conductors while preserving the standard M8 electrical interface. The threaded coupling mechanism secures both connector ends against vibration and accidental loosening.
The molded connector bodies protect internal electrical terminations against dust and water ingress when correctly connected to compatible equipment, maintaining reliable operation in industrial production areas.
Typical Applications
- Photoelectric sensors
- Inductive proximity sensors
- Machine safety devices
- Compact automation equipment
- Packaging machinery
- Robot end-of-arm tooling
- Automated assembly systems
- Industrial conveyors
Industrial Applications
Robotic Cells
The right-angle connector allows sensor wiring inside confined robotic fixtures where straight connectors may interfere with moving components or protective covers.
Packaging Equipment
Compact packaging machines often provide limited installation space around sensors. The angled connector simplifies cable routing while reducing mechanical stress at the connector exit.
Electronics Manufacturing
Assembly stations equipped with compact positioning sensors benefit from low-profile cable routing that helps keep work areas organized.
Automated Material Handling
Conveyor-mounted sensors positioned near guide rails or machine frames can be connected more efficiently using right-angle cable assemblies.
Advantages
- Right-angle connector supports compact installations.
- PUR cable provides excellent flexibility and oil resistance.
- Factory-molded connectors eliminate field wiring.
- Four-pin M8 interface supports standard automation devices.
- IP67 protection helps maintain reliable operation.
- Designed for dynamic industrial environments.
- Secure threaded locking resists vibration.
Selection Considerations
- Verify that a right-angle connector is required.
- Confirm the 1-meter cable length matches installation requirements.
- Check compatibility with four-pin M8 equipment.
- Review voltage and current specifications.
- Ensure sufficient cable bend radius during installation.
- Inspect connector seals after assembly.
Additional connector configurations and compatible accessories are available within the
Omron sensor series.
Frequently Asked Questions
1. What connector configuration does this cable use?
It features a right-angle M8 female connector and a straight M8 male connector.
2. Why is a right-angle connector useful?
It simplifies cable routing in confined spaces and reduces mechanical stress where clearance is limited.
3. How many contacts are provided?
The cable contains four electrical contacts.
4. What is the cable length?
The overall cable length is 1 meter.
5. Which cable material is used?
The assembly uses a PUR oil-resistant robot cable suitable for dynamic industrial applications.
6. What environmental protection does it provide?
When connected correctly, the assembly meets IP67 protection requirements.
7. Is field wiring required?
No. Both connectors are factory molded, allowing direct installation without connector termination.
8. Can the cable be used with industrial sensors?
Yes. The Omron XS3W-M422-401-PR Extension Cable is intended for compatible M8-connected sensors, actuators, and automation devices used throughout industrial control systems.
