Omron S8VS-12024BP 120W 24VDC DIN Rail Power Supply
The Omron S8VS-12024BP is a 120 W switch mode power supply developed to provide reliable 24 VDC power in industrial automation and control applications. With a rated output current of 5 A, integrated indication functions and DIN rail mounting, it supports efficient power distribution within control panels, machinery and production systems.
This model includes a total run time monitor, output voltage and current indication, peak-hold current display and an undervoltage alarm. These monitoring capabilities help maintenance teams observe operating conditions, identify abnormal power situations and plan preventive maintenance activities more effectively.
Omron S8VS-12024BP Stable 24 VDC Power for Industrial Equipment
Industrial control components require a consistent DC supply to operate reliably. The unit delivers a rated 24 VDC output and allows voltage adjustment from -10% to +15% through the V.ADJ function. Its 5 A rated output current makes it suitable for powering PLC systems, relays, sensors, communication modules, operator panels and other control devices.
The power supply accepts a rated input voltage range of 100 to 240 VAC and can operate within an allowable AC input range of 85 to 264 VAC. It also supports a DC input range of 80 to 370 VDC, providing flexibility for different industrial electrical infrastructures.
Omron S8VS-12024BP Integrated Monitoring Functions
A major advantage of this model is its indication monitor. Operators can switch between output voltage, output current, peak-hold current and total operating time information. The total run time monitor supports maintenance planning by providing greater visibility into how long the power supply has been operating.
The undervoltage alarm provides both visual indication and transistor output. This function can assist control systems in detecting output voltage conditions that may affect connected equipment. The sourcing transistor output is rated for up to 30 VDC and 50 mA.
Omron S8VS-12024BP Protection and Installation Features
- 120 W rated power capacity
- 24 VDC rated output voltage
- 5 A rated output current
- 100 to 240 VAC rated input
- Output voltage, current and peak-current indication
- Total run time monitoring
- Undervoltage alarm output
- Automatic-reset overload protection
- Overvoltage protection
- Screw terminal connections
- DIN rail mounting
The covered housing and screw terminal block support organized installation in industrial control cabinets. Automatic-reset overload protection and overvoltage protection help safeguard the power supply and connected components during abnormal electrical conditions.
Typical Application Areas
The Omron S8VS series can be used in machine control panels, packaging systems, material-handling equipment, production lines, process automation installations and OEM machinery. Its monitoring functions are particularly valuable in systems where maintenance visibility and operational continuity are important.
Product Selection and Availability
Before installation, engineers should confirm the connected load, starting current, ambient temperature, mounting arrangement and required monitoring outputs. Correct sizing provides sufficient capacity and supports reliable operation throughout the equipment lifecycle.
