Omron S8VK-WB24048 240W 48VDC 5A Three-Phase Power Supply
The Omron S8VK-WB24048 is a compact switch mode power supply designed to provide a stable 48 VDC output for industrial automation and machine control systems. With a rated output capacity of 240 W and 5 A, it supports professional applications where reliable DC power, efficient panel installation and operational continuity are important. Companies can contact Emaconn to request current pricing, product availability, lead-time information and technical selection assistance.
Stable 48VDC Power for Industrial Equipment
Industrial control systems depend on consistent power quality to operate controllers, communication equipment, relays, sensors and other electronic devices. This model converts three-phase or two-phase AC input into a regulated 48 VDC output, helping maintain dependable system operation under demanding production conditions.
Its supported input range of 320 to 576 VAC makes it suitable for facilities using nominal 380 to 480 VAC industrial power networks. The unit can also accept 450 to 810 VDC input, subject to the application requirements and installation instructions.
Omron S8VK-WB24048 Key Technical Specifications
| Product series | S8VK-WB |
|---|---|
| Rated power | 240 W |
| Rated output voltage | 48 VDC |
| Rated output current | 5 A |
| Power Boost current | 7.5 A |
| Input voltage range | 320–576 VAC or 450–810 VDC |
| Output adjustment range | 48–56 VDC |
| Typical efficiency | 93% at three-phase 400 VAC input |
| Operating temperature | -40°C to +70°C with applicable derating |
| Protection rating | IP20 |
| Mounting method | DIN rail |
Omron S8VK-WB24048 Push-In Plus Wiring and Status Monitoring
Push-In Plus terminals help reduce wiring time while supporting secure electrical connections inside industrial cabinets. The compact DIN rail design also helps panel builders use available cabinet space efficiently.
Integrated INPUT OK, DC OK and Iout > 100% indicators simplify visual status checks. Signal outputs for DC OK and excessive output current can support system monitoring and preventive maintenance strategies. Automatic overload protection and overvoltage protection contribute to safer operation when abnormal electrical conditions occur.
Typical Application Areas
- PLC and industrial control cabinets
- Machine automation systems
- Robotics and material-handling equipment
- Process control installations
- Packaging and production machinery
- Industrial communication systems
- OEM electrical panels
Selection and Purchasing Guidance
Before ordering, users should verify the available input supply, required 48 VDC load current, temporary peak-current demand, cabinet temperature and available DIN rail space. The total continuous load should remain within the rated 5 A output, while sufficient engineering margin should be considered for future expansion.
For current commercial terms, delivery options and compatibility support, contact Emaconn before finalising the order. More information about Omron industrial automation products is available on the Omron product page.
Omron S8VK-WB24048 Frequently Asked Questions
What is the rated output of this power supply?
It provides a rated 48 VDC output at 5 A, corresponding to 240 W of output power.
Does the product support temporary peak loads?
Yes. Its Power Boost function can provide up to 7.5 A under the operating conditions defined by Omron.
Can it be installed on a DIN rail?
Yes. The unit is designed for DIN rail installation inside suitable industrial electrical cabinets.
How can price and availability be requested?
Customers can contact Emaconn with the complete model number to obtain current price, availability and estimated delivery information.
