Omron G2RV-SR500-AP 200VAC Slim I/O Relay

Technical Overview

The Omron G2RV-SR500-AP 200VAC slim I/O relay is designed for compact industrial control panels where reliable signal switching and space efficiency are both important. As part of the G2RV-SR family, this relay uses a narrow 6.2 mm profile, making it suitable for dense DIN rail layouts in automation cabinets, machine control systems, and PLC interface circuits.

This model features a 200VAC rated input voltage and an SPDT contact arrangement, commonly described as 1 Form C. The contact rating supports up to 6A at 250VAC, depending on the applied load and installation conditions. The “AP” designation identifies the microload contact version, which is useful where low-level signal switching needs stable contact behavior.

Design and Installation Benefits

The relay includes Push-In Plus terminal technology, helping technicians reduce wiring time while keeping conductors firmly seated. Its integrated slim relay and socket structure simplifies replacement and inspection. LED operation indication and a mechanical indicator make status checks easier during commissioning, maintenance, and troubleshooting.

Because the G2RV-SR500-AP version does not include a latching lever, it is often selected for applications where straightforward relay operation is preferred without manual test switching. For broader Omron relay information, visit Omron slim relay information.

Typical Applications

The Omron G2RV-SR500-AP 200VAC slim I/O relay is suitable for machine panels, HVAC control systems, industrial signal interfaces, safety-related indication circuits, and compact electrical cabinets. Its slim design supports high channel density, while the microload contact structure makes it practical for sensitive control signals.

FAQ

What type of relay is the Omron G2RV-SR500-AP 200VAC?

It is a slim DIN rail I/O relay with Push-In Plus terminals, SPDT contacts, LED indication, and a 200VAC input rating.

What does AP mean in this model?

AP indicates the microload contact version, intended for applications where smaller control signals require dependable switching performance.

Is this relay suitable for compact panels?

Yes. Its 6.2 mm slim body makes it especially suitable for control panels where space optimization is a key requirement.

Does it have a manual test lever?

No. The SR500 configuration is supplied without a latching test lever.

Where is this relay commonly used?

It is commonly used in PLC interfaces, automation panels, machine control cabinets, and industrial signal switching circuits.
