Omron G2RV-SR500 24VAC/DC relay-Socket Guide

Omron G2RV-SR500 24VAC/DC relay-Socket is a flexible slim interface relay designed for both 24VAC and 24VDC control circuits. This dual-voltage compatibility makes it highly useful in automation panels where AC and DC control signals may exist in different sections of the same system.

Technical Overview

The relay features a 24VAC/DC coil, SPDT contact form, non-latching operation, and silver alloy contact material. It supports 6A contact current and is suitable for DIN rail mounting. Its operating and release response times are appropriate for standard industrial control applications, while the slim body supports dense panel layouts.

Push-In Plus terminal technology makes conductor insertion more efficient and helps reduce wiring errors. The relay also includes LED indication and a mechanical operation display, allowing technicians to verify coil energization and contact movement visually. This is especially helpful in PLC output circuits, sensor interfaces, and machine safety-related auxiliary circuits where quick inspection matters.

Common Applications

Omron G2RV-SR500 24VAC/DC relay-Socket is used in PLC interface modules, control panels, building automation, packaging machines, conveyor lines, pump control circuits, and general industrial automation. Because it works with both AC and DC 24V control supplies, it gives designers more flexibility during panel standardization.

Why Engineers Prefer It

In modern control panels, component width, wiring speed, and maintenance visibility directly affect long-term system efficiency. This relay socket combines compact installation with clear diagnostics and reliable switching. For related Omron solutions, visit Omron industrial automation products.

FAQ

What is the main advantage of 24VAC/DC compatibility?

It allows the same relay model to be used in both 24V AC and 24V DC control circuits, reducing part complexity in panel design.

Is Omron G2RV-SR500 24VAC/DC suitable for PLC outputs?

Yes. It is commonly used as an interface relay between PLC outputs and field devices, especially where signal isolation is needed.

What contact rating does it offer?

The relay is rated for 6A switching current, making it suitable for many control and auxiliary load applications.

Does it use screw terminals?

No. The SR500 version uses Push-In Plus spring terminals, which support faster and more consistent wiring.

Can it be used in tight control panels?

Yes. Its slim DIN rail design helps save cabinet space and keeps wiring layouts clean.
