Omron G2R-2-SN 12VAC (S) Relay Socket

The Omron G2R-2-SN 12VAC (S) Relay Socket is a compact plug-in relay developed for low-voltage AC control circuits. With its 12 VAC coil, DPDT contact structure and 5 A rated carry current, it is widely used in automation panels, machine control systems and interface circuits where safe low-voltage switching is preferred.

Technical Characteristics

This relay uses a 2-pole DPDT contact arrangement, allowing two independent circuits to be switched from a single coil operation. It includes LED indication and a mechanical operation indicator, giving technicians a clear visual reference during commissioning and maintenance. The transparent case also supports faster inspection in dense control cabinets.

Application Areas

The Omron G2R-2-SN 12VAC (S) relay is suitable for low-voltage control panels, signal isolation, small machine automation, auxiliary switching and equipment interface tasks. The 12 VAC coil makes it relevant for systems where control voltage is intentionally kept low for safety, compatibility or design reasons.

Installation and Panel Compatibility

As a plug-in relay, this model is designed to work with compatible relay sockets. This helps reduce downtime because the relay can be removed and replaced without rewiring the entire circuit. In panel design, that can be a major advantage for maintenance efficiency and lifecycle management.

For more about Omron, related relay socket families and industrial automation components can be reviewed.

FAQ

What is Omron G2R-2-SN 12VAC (S) used for?

It is used for low-voltage AC switching, signal interposing and control panel relay applications.

What is the contact configuration?

The relay has a DPDT contact configuration, also known as 2 Form C.

Why choose a 12 VAC relay?

A 12 VAC relay is useful when the control circuit is designed around low-voltage alternating current for safer or more specific machine control needs.

Does it include an LED?

Yes. The relay includes an LED indicator, which helps users confirm coil energization visually.

Can it be replaced easily?

Yes. Its plug-in design allows easier replacement when used with the correct compatible socket.
