Omron E2E-X20D130-TR 5M Inductive Proximity Sensor

Technical Description

Industrial automation systems frequently require reliable target detection without physical contact. The Omron E2E-X20D130-TR 5M Inductive Proximity Sensor is designed to address this requirement by providing stable metallic object detection within a compact M30 threaded housing. As a member of the E2E NEXT series, this sensor combines long sensing capability with robust environmental protection, supporting operation in demanding manufacturing environments.

The Omron E2E-X20D130-TR 5M Inductive Proximity Sensor features a 20 mm sensing distance and an integrated 5-meter cable, allowing installation flexibility in machinery where control cabinets or I/O modules are positioned further from the sensing location.

Operating Principle

The sensor operates using inductive sensing technology. An internal oscillator creates an electromagnetic field at the sensing face. When a metallic object enters the field, eddy currents are generated within the target material. These currents alter the oscillation characteristics, enabling the sensor electronics to identify the target and activate the output signal.

This detection process occurs without direct contact, helping reduce wear and enabling consistent operation throughout repetitive production cycles.

Main Features

Extended Detection Distance

The 20 mm sensing range supports applications where larger installation tolerances are required and where targets may not consistently approach the sensor at minimal distances.

Long-Distance Wiring Capability

The factory-installed 5-meter cable simplifies installation in larger machines and production lines that require extended wiring routes.

Enhanced Environmental Resistance

IP67, IP67G, and IP69K protection ratings help protect internal electronics against dust ingress, moisture exposure, coolant contamination, and washdown procedures.

Applications

• Automated conveyor systems
• Machine position monitoring
• Metal component detection
• Packaging equipment
• Transfer and handling machinery
• Assembly line automation
• Industrial transport systems
• Production monitoring stations

Industrial Applications

The sensor is utilized in production environments where reliable object detection contributes to process control, equipment synchronization, and operational consistency.

• Automotive assembly plants
• Metalworking operations
• Industrial packaging facilities
• Warehouse automation systems
• Machine building projects
• Robotic handling equipment
• Logistics and distribution centers

Advantages

• Non-contact metal detection
• 20 mm sensing distance
• Long 5 m cable connection
• Durable nickel-plated brass housing
• Resistance to industrial contaminants
• Suitable for high-cycle automation tasks
• Reduced mechanical wear
• Stable detection performance

Industry Use Cases

Automated Material Flow Systems

The sensor can monitor carrier positions and detect metallic transport components throughout automated material movement processes.

Machine Tool Equipment

Used to verify mechanical positioning of moving machine elements operating near lubricants and metal debris.

Production Line Monitoring

Supports process sequencing by detecting metal fixtures, pallets, and tooling components moving between workstations.

Important Selection Criteria

When choosing an inductive proximity sensor, it is important to evaluate the required sensing distance, target dimensions, installation space, environmental conditions, and cable routing requirements. Long cable versions can simplify installation where sensors are positioned far from control hardware.

Additional information about related sensing technologies can be found within Omron sensor product ranges.

Frequently Asked Questions

What sensing technology does this sensor use?

It uses inductive sensing technology for metallic target detection.

What is the nominal sensing distance?

The sensor provides a nominal sensing distance of 20 mm.

What output type is available?

The model uses a DC 2-wire output configuration.

How long is the connection cable?

The sensor is supplied with a 5-meter pre-wired cable.

Can the sensor operate in washdown environments?

Yes. IP67, IP67G, and IP69K ratings support operation in demanding industrial conditions.

Does the sensor detect non-metallic materials?

No. The sensing principle is intended for metallic targets.

Where is this model commonly used?

It is widely used in conveyors, machinery, packaging equipment, and automated production systems.

What material is used for the housing?

The housing is constructed from nickel-plated brass for enhanced durability.
