Elesa+Ganter 113007 HCK.127-ZN-M12-NBR-PC-P-STL Column Level Indicator

The Elesa+Ganter 113007 column level indicator is designed for clear oil level monitoring in hydraulic tanks, lubrication units and industrial fluid systems where visual inspection and temperature awareness matter. Its HCK.127 configuration refers to a 127 mm fixing hole centre distance, making it suitable for compact installations that still require dependable readability.

Technical Overview

This model uses glass-fibre reinforced polyamide based technopolymer assembly ends, a natural aluminium support and a transparent polycarbonate tube intended for oil applications. The NBR synthetic rubber O-ring supports continuous working temperatures up to 100°C, while the PC front protection improves durability during routine maintenance and shop-floor use.

The STL suffix identifies the integrated PT100 electrical temperature probe. This makes the indicator more than a simple sight column: it helps operators observe oil level and track temperature-related conditions from the same assembly. The M12 connection, 12.5 mm mounting hole and recommended maximum tightening torque of 12 Nm support secure installation when mounted correctly.

Elesa+Ganter 113007 Where It Is Commonly Used

Industrial users often choose this type of oil level indicator for hydraulic power packs, machine tools, presses, lubrication reservoirs and production equipment. The visible column helps maintenance teams identify level changes quickly, while the temperature probe can support preventive maintenance strategies.

Why The Specification Matters

A 56 mm visible level range provides practical local reading without adding unnecessary panel height. The polycarbonate tube keeps the design lightweight and impact resistant for oil service. For systems exposed to unusual fluids, higher pressure or non-standard temperature profiles, compatibility should always be checked under real operating conditions.

Elesa+Ganter 113007 For more information about Elesa+Ganter, you can review related industrial component options.

Elesa+Ganter 113007 FAQ

What is the Elesa+Ganter 113007 used for?

It is used to visually monitor oil level in hydraulic and lubrication systems while also supporting temperature measurement through its PT100 probe.

Is this model suitable for oil?

Yes. The PC transparent tube version is intended for oil applications. Fluid compatibility should still be verified for each installation.

Elesa+Ganter 113007 What does STL mean in this product code?

STL refers to the PT100 electrical temperature probe, which allows temperature monitoring in addition to level indication.

What is the mounting size?

The HCK.127 version has a 127 mm hole centre distance and uses an M12 mounting arrangement.
