Weidmüller VGM25-MS54ZE BS9-19 Metal Cable Gland Overview
The Weidmüller VGM25-MS54ZE BS9-19 is an industrial metal cable gland developed for cable entry sealing and mechanical strain relief. High-interest searches around M25 cable gland, brass cable gland, industrial cable entry gland, and strain relief cable gland show how important this category is in enclosure design. A cable gland may be a small line item in a bill of materials, but it has direct impact on protection level, durability, and maintenance performance.
What is the Weidmüller VGM25-MS54ZE BS9-19?
The Weidmüller VGM25-MS54ZE BS9-19 product type cable gland is associated with the VGM25-MS54 ZE family. Official family references describe this class as a straight M25 cable gland used to seal housings when introducing cables and to provide strain relief. The family is identified as nickel-plated brass and linked to IP54 protection, rising to IP65 with GWDR according to the indexed family page. The family listing also shows the M25 version handling a cable outer diameter range starting at 9 mm.
The requested part code includes the suffix BS9-19, which aligns with the specified cable range designation in the order code. In practical selection work, that matters because cable glands must be matched closely to cable outer diameter for reliable sealing and strain relief.
Core technical properties
Public Weidmüller family data for the VGM25-MS54 ZE identifies M25 metric thread, straight form, and nickel-plated brass construction. The same source indicates IP54 protection as standard and a higher protection value with the appropriate accessory arrangement. Key width references are also published in family data, underscoring that the gland is intended for serious industrial mounting rather than light-duty consumer use.
For engineers, these details translate into predictable enclosure integration. M25 is a common size where larger industrial cables must enter a cabinet or housing without compromising mechanical quality. Brass construction supports strength, while nickel plating helps suit the harsher realities of industrial environments.
Why larger cable glands are often essential
Not every installation can use compact cable entry hardware. Where larger control, power, or hybrid cables are involved, a gland like the Weidmüller VGM25-MS54ZE BS9-19 brass cable gland becomes necessary. A gland that is too small will not seal or clamp correctly. A gland that is too large may fail to provide proper strain relief. Correct sizing is therefore a functional requirement, not just a mechanical preference.
This is why searchers often compare phrases like M25 brass cable gland, industrial enclosure cable gland, and metal cable gland for large cable diameter. They are trying to ensure that enclosure performance and cable support remain aligned.
Typical applications
The Weidmüller VGM25-MS54ZE BS9-19 industrial cable gland is relevant in machinery, control panels, junction enclosures, outdoor-capable cabinets, utility-related housings, and industrial assemblies where thicker cables require reliable sealing and retention. It is especially useful where cable movement, servicing, or environmental exposure makes a plastic light-duty entry solution less appropriate.
Selection and installation perspective
Cable gland performance depends not only on the part itself but also on correct installation. Thread compatibility, tightening practice, sealing accessory use, and matching to actual cable diameter all influence the final result. That is why careful datasheet verification remains essential, particularly when the order code includes a cable range indicator such as BS9-19.
FAQ
What is the Weidmüller VGM25-MS54ZE BS9-19 used for?
It is used for sealed cable entry into an enclosure while also providing mechanical strain relief for the cable.
What thread size does this model use?
Public family references identify the VGM25-MS54 ZE as an M25 cable gland.
What material is the gland family made from?
The indexed Weidmüller family page describes it as brass with nickel plating.
What protection level is associated with the family?
Public family information lists IP54 protection as standard and IP65 with GWDR in the referenced family configuration.
Why is the BS9-19 designation important?
It points to the cable size range variant, which is critical because the gland must fit the cable outer diameter correctly to seal and clamp as intended.
Where would this cable gland normally be used?
It is commonly used in industrial enclosures, cabinets, machines, and equipment housings that require robust cable support and protected cable entry.
For more information about Weidmüller enclosure and cable entry solutions, the larger product family is useful when comparing thread sizes and sealing classes.
