Weidmüller TOP 24VDC 24VDC2A Solid-State Relay Guide

The Weidmüller TOP 24VDC 24VDC2A solid-state relay is a TERMSERIES product designed for digital signal switching where compact size, silent operation, and fast switching behavior are important. Also listed as Weidmüller 2618720000 solid-state relay, the official product information describes it as a solid-state relay for switching and amplifying digital signals that operates wear-free and noiselessly. It uses a 24 V DC ±20% rated control voltage, a 3…33 V DC rated switching voltage, a 2 A continuous current rating, and PUSH IN connection technology.

Why the Weidmüller TOP 24VDC 24VDC2A is a practical SSR

Solid-state relays are often chosen when designers want switching without the wear and audible clicking associated with electromechanical relays. The Weidmüller TOP 24VDC 24VDC2A fits that need in compact industrial systems that use DC control and DC load switching. The PUSH IN connection is another strong advantage because it supports faster installation and efficient repetitive panel assembly.

Technical characteristics that shape performance

Official product data lists a 2 A continuous current, a 15 A inrush current for 10 ms, an LED green status indication, free-wheel diode and reverse polarity protection, plus an on-delay of ≤0.1 ms and off-delay of <1 ms. Those details help show why the Weidmüller 2618720000 solid-state relay is relevant in fast, compact DC switching tasks where signal responsiveness and low maintenance are priorities.

Typical applications

The Weidmüller TOP 24VDC 24VDC2A solid-state relay is suitable for industrial control panels, automation systems, compact signal interfaces, and digital switching applications where quiet operation and high switching endurance are valued. Because it belongs to the TERMSERIES family, it also aligns well with modular cabinet concepts that prioritize slim interface design. For more information about related solid-state products, visit Weidmüller solutions.

FAQ about the Weidmüller TOP 24VDC 24VDC2A

What is the Weidmüller TOP 24VDC 24VDC2A?

It is a TERMSERIES solid-state relay for DC control and DC load switching.

What is the control voltage of the Weidmüller 2618720000?

The relay uses a 24 V DC ±20% rated control voltage.

What switching voltage does it support?

The load side is specified for 3…33 V DC.

What is the continuous current rating?

It is rated for 2 A continuous current.

What connection method does it use?

This version uses PUSH IN connection technology.

Why would someone choose this solid-state relay?

Because it offers wear-free, noiseless operation, fast switching behavior, and compact DC interface performance.
