Weidmüller LL 5.08/13/90 3.2SN OR BX PCB Terminal Block
The Weidmüller LL 5.08/13/90 3.2SN OR BX PCB terminal block is intended for industrial board-level applications where a 13-pole connection layout can provide a more exact fit than a lower or more standardized terminal count. In product development, that kind of precision is valuable because it supports a cleaner PCB layout, more logical wiring structure, and improved installation clarity for technicians and end users.
Product Overview
The Weidmüller LL 5.08/13/90 3.2SN OR BX is a PCB terminal block with 13 poles, a 5.08 mm pitch, and a 90-degree conductor outlet. It is equipped with 3.2 mm tinned solder pins, an orange housing, and a clamping yoke screw connection. This makes it well suited to direct wire termination on PCBs used in industrial electronics, machine systems, and building technology equipment.
Search intent around the Weidmüller LL 5.08/13/90 3.2SN OR BX PCB terminal block often includes terms such as 13-pole PCB terminal block, right-angle 5.08 mm board terminal, or Weidmüller industrial terminal for PCB-mounted control and interface systems.
Technical Features
- Product type: PCB terminal block
- Pitch: 5.08 mm
- Number of poles: 13
- Conductor outlet direction: 90°
- Solder pin length: 3.2 mm
- Pin finish: tinned
- Housing colour: orange
- Connection system: clamping yoke connection
- Maximum clamping range: 6 mm²
- IEC rating: 500 V / 32.5 A / 0.5–6 mm²
- UL rating: 300 V / 20 A / AWG 26–12
- Packaging: Box
Why the 13-Pole Version Is Useful
A 13-pole terminal block is useful in applications where the board interface requires a higher connection count but not one that falls neatly into even-numbered standard sizes. The Weidmüller LL 5.08/13/90 3.2SN OR BX terminal block allows engineers to choose a more exact fit, which can reduce unused positions and help simplify circuit grouping.
That accuracy supports better schematics, easier marking, and more disciplined internal architecture. In real industrial products, terminal sizing decisions like this can influence both manufacturing efficiency and field service convenience.
Connection and Layout Advantages
The clamping yoke screw connection remains highly practical because it offers secure conductor retention and a service-friendly installation method familiar to industrial technicians. The Weidmüller LL 5.08/13/90 3.2SN OR BX PCB terminal block also benefits from the 90-degree conductor outlet, which helps route wires along the PCB plane and can improve cable management inside compact housings.
This combination makes the product well suited to installations where service access, wiring clarity, and mechanical stability are all important considerations.
Application Areas
This terminal block may be used in process interfaces, machine control boards, industrial monitoring systems, building automation electronics, OEM device assemblies, and energy-related electronics. Its conductor range and current performance allow it to support more demanding board-level wiring tasks than lighter-duty alternatives.
FAQ
What is the Weidmüller LL 5.08/13/90 3.2SN OR BX used for?
It is used for direct wire termination on industrial PCBs where thirteen positions are needed in a single organized terminal block.
Why choose a 13-pole terminal block?
It helps match the terminal precisely to the circuit layout without forcing a compromise to a less suitable standard size.
Is this suitable for industrial electronics?
Yes. Its technical ratings and clamping yoke connection make it suitable for many industrial board applications.
What is the value of the 5.08 mm pitch?
It is a proven industrial pitch that supports practical conductor spacing and reliable installation.
Does the right-angle outlet improve PCB integration?
Yes. It supports lateral cable routing and can make enclosure design more efficient.
