Weidmüller LL 5.08/10/90 3.2SN OR BX PCB Terminal Block
The Weidmüller LL 5.08/10/90 3.2SN OR BX PCB terminal block is a versatile industrial board terminal designed for applications that require a well-balanced connection count, dependable screw-based conductor clamping, and efficient right-angle cable routing. In control engineering and board-level device design, a 10-pole terminal block is one of the most widely used formats because it supports a broad range of grouped signal and power-related tasks without making the connection area unnecessarily complex.
Product Overview
The Weidmüller LL 5.08/10/90 3.2SN OR BX is a PCB terminal block with 10 poles, a 5.08 mm pitch, and a 90-degree conductor outlet direction. It features 3.2 mm tinned solder pins, an orange housing, and a clamping yoke screw connection. This makes it suitable for THT board integration in industrial assemblies that require a secure direct wire-to-board interface.
When users search for the Weidmüller LL 5.08/10/90 3.2SN OR BX PCB terminal block, they are often looking for a 10-pole PCB terminal, a 5.08 mm industrial board terminal, or a Weidmüller screw-clamp terminal for control boards and interface electronics.
Technical Features
- Product type: PCB terminal block
- Pitch: 5.08 mm
- Number of poles: 10
- Conductor outlet direction: 90°
- Solder pin length: 3.2 mm
- Pin finish: tinned
- Housing colour: orange
- Connection method: clamping yoke connection
- Maximum clamping range: 6 mm²
- IEC rating: 500 V / 32.5 A / 0.5–6 mm²
- UL rating: 300 V / 20 A / AWG 26–12
- Packaging: Box
Why 10 Poles Is a Popular Format
A 10-pole board terminal is popular because it supports a wide variety of circuit grouping strategies. It may be used for combined control and reference lines, grouped low-voltage outputs, monitoring circuits, or compact power-related board terminations. The Weidmüller LL 5.08/10/90 3.2SN OR BX terminal block gives engineers a familiar, flexible format that fits many industrial electronics designs.
From a layout perspective, 10 poles often provide a strong balance between connection capacity and manageable PCB edge length. This can help reduce the need for multiple fragmented terminal sections and lead to a cleaner wiring architecture.
Installation and Practical Value
The clamping yoke screw connection used here offers dependable conductor retention and a service-friendly connection method. Because many technicians already work with similar screw-based terminals across industrial systems, the learning curve is minimal. That makes the Weidmüller LL 5.08/10/90 3.2SN OR BX PCB terminal block attractive in products designed for long service life and repeatable maintenance.
The 90-degree conductor outlet also adds practical value by supporting side-entry wiring. In shallow housings and compact electrical assemblies, this helps preserve space and keep internal cable paths more organized.
Typical Applications
This terminal block can be found in machine controls, industrial monitoring boards, HVAC electronics, process interface modules, building control devices, and OEM assemblies that need direct PCB wiring with stronger conductor capacity. Its electrical ratings and conductor range support more than basic signal use.
FAQ
What is the Weidmüller LL 5.08/10/90 3.2SN OR BX?
It is a 10-pole PCB terminal block with a 5.08 mm pitch and clamping yoke screw connection for industrial board-level applications.
Why is a 10-pole terminal block so common?
It offers a useful balance between terminal capacity and compact design, making it suitable for many grouped wiring tasks.
Is the product suitable for industrial control systems?
Yes. Its ratings and construction make it well suited to industrial control, automation, and interface electronics.
What is the advantage of 3.2 mm solder pins?
They support THT board integration with a defined solder pin length suitable for stable PCB mounting.
Does a right-angle terminal help in compact devices?
Yes. It improves wire routing along the board and helps manage enclosure space more effectively.
Where can I view more from this manufacturer?
For more information about Weidmüller, related PCB terminal product families are worth reviewing.
