Weidmüller LL 5.00/24/90 3.2SN OR BX PCB Terminal Block
The Weidmüller LL 5.00/24/90 3.2SN OR BX PCB terminal block is developed for applications that need a large number of termination points in a single structured board terminal. In industrial electronics, a 24-pole terminal block is especially relevant for devices with extensive I/O, grouped control signals, or larger wiring sets that still benefit from a direct and serviceable PCB connection concept.
Product Overview
The Weidmüller LL 5.00/24/90 3.2SN OR BX is a 24-pole PCB terminal block with 5.00 mm pitch, a 90-degree conductor outlet direction, 3.2 mm tinned solder pins, and orange housing. It uses a clamping yoke screw connection and is packaged in a box. As part of the LL series, it is aimed at industrial board applications where secure conductor retention and clear terminal organization matter.
Technical Features
- Product type: PCB terminal block
- Pitch: 5.00 mm
- Number of poles: 24
- Conductor outlet direction: 90°
- Solder pin length: 3.2 mm
- Pin finish: tinned
- Connection method: clamping yoke connection
- Maximum clamping range: 6 mm²
- IEC rating: 500 V / 32.5 A / 0.5–6 mm²
- UL rating: 300 V / 20 A / AWG 26–12
- Packaging: Box
Why a 24-Pole PCB Terminal Block Can Be Strategic
The 24-pole format makes it possible to concentrate a broad set of field connections into one terminal line. The Weidmüller LL 5.00/24/90 3.2SN OR BX terminal block can therefore support more efficient board layout planning, clearer terminal numbering, and reduced use of separate smaller terminal components.
In complex industrial systems, this kind of consolidation can simplify assembly, reduce wiring confusion, and improve field service visibility. Instead of tracing multiple separated termination points, technicians can work from one organized connection strip.
Mechanical and Installation Value
The clamping yoke screw connection provides dependable conductor retention and is easy to understand for installers and maintenance personnel. The right-angle conductor outlet is also particularly helpful on a large terminal block because it keeps wires aligned along the board and can prevent the connection area from becoming visually cluttered.
The Weidmüller LL 5.00/24/90 3.2SN OR BX PCB terminal block is especially attractive when larger conductor sizes and stronger current capacity are needed directly at the PCB level.
Where This Product Is Commonly Relevant
This terminal block can be used in larger control systems, extensive interface boards, industrial monitoring devices, process electronics, building technology hardware, and OEM machine control products. It is also relevant where a standardized terminal concept is used across multiple device generations.
FAQ
What is the Weidmüller LL 5.00/24/90 3.2SN OR BX?
It is a 24-pole PCB terminal block with 5.00 mm pitch and clamping yoke screw connection for industrial board-level wiring.
Why choose a 24-pole terminal block?
It helps group a high number of circuits into one organized terminal line, which can simplify wiring and service work.
Is it suitable for larger industrial boards?
Yes. A 24-pole format is especially useful on larger boards or systems with multiple grouped wiring functions.
What is the benefit of the right-angle design?
It keeps wire routing parallel to the PCB and supports a more orderly internal cable layout.
Does this product support industrial conductor sizes?
Yes. The published data indicates support up to 6 mm² under IEC and AWG 12 under UL.
Where can I explore more from the same manufacturer?
For more information about Weidmüller, reviewing related PCB terminal solutions can help compare pole counts and layouts.
