Weidmüller LL 5.00/16/90 3.2SN OR BX PCB Terminal Block
The Weidmüller LL 5.00/16/90 3.2SN OR BX PCB terminal block is a robust board terminal for industrial electronics that require a higher number of connection points in one structured terminal section. In practical design work, a 16-pole PCB terminal is often selected when engineers want to consolidate wiring, reduce terminal fragmentation on the PCB, and keep installation and servicing more manageable.
Product Description
The Weidmüller LL 5.00/16/90 3.2SN OR BX is a 16-pole PCB terminal block with a 5.00 mm pitch and 90-degree conductor outlet. It includes 3.2 mm tinned solder pins, orange housing, and a clamping yoke screw connection. This format is intended for THT board integration and supports direct conductor termination on the PCB for industrial equipment.
Technical Summary
- Product type: PCB terminal block
- Pitch: 5.00 mm
- Number of poles: 16
- Conductor outlet direction: 90°
- Solder pin length: 3.2 mm
- Pin finish: tinned
- Connection style: clamping yoke screw connection
- Maximum clamping range: 6 mm²
- IEC rating: 500 V / 32.5 A / 0.5–6 mm²
- UL rating: 300 V / 20 A / AWG 26–12
- Packaging: Box
Why 16 Poles Can Improve Board Design
The 16-pole format is useful for applications that need a broader wiring interface while still benefiting from one continuous terminal arrangement. The Weidmüller LL 5.00/16/90 3.2SN OR BX terminal block can help simplify PCB edge planning, especially in control systems and interface devices where multiple circuits must be brought together clearly.
Instead of splitting related conductors across multiple terminals, designers can create a more unified terminal strategy. This often improves assembly logic and supports cleaner documentation.
Connection and Service Benefits
The clamping yoke screw connection continues to be valued for its secure wire hold and familiar maintenance process. In many industrial environments, that familiarity is essential because service personnel need to work quickly and confidently with existing installations. The right-angle conductor outlet also supports lateral cable paths, which can reduce clutter and improve space efficiency inside the device.
Because the Weidmüller LL 5.00/16/90 3.2SN OR BX PCB terminal block supports conductors up to 6 mm², it fits a broad range of industrial board-level wiring scenarios.
Common Use Cases
Typical applications include machine controller boards, industrial communication electronics, energy management devices, HVAC control systems, and OEM automation modules. The 16-pole format is especially practical when a product needs a larger organized terminal section but still wants to keep a standard 5.00 mm pitch concept.
FAQ
What is the Weidmüller LL 5.00/16/90 3.2SN OR BX used for?
It is used for direct PCB wire termination in industrial devices that require 16 connection positions in one terminal block.
Why choose a 16-pole terminal block?
It allows more circuits to be grouped into a single terminal arrangement, which can improve wiring structure and reduce component fragmentation.
Is the screw connection suitable for long-term industrial use?
Yes. It is a well-established connection method widely used in industrial board terminals.
Does the product support larger conductors?
Yes. According to published data, it supports up to 6 mm² under IEC.
What is the advantage of the 90-degree outlet?
It helps keep wires parallel to the board, which supports cleaner cable routing and more efficient use of enclosure space.
Where can I review more brand information?
For more information about Weidmüller, comparing other PCB terminal formats in the same family is recommended.
