Weidmüller LL 5.00/14/90 3.2SN OR BX PCB Terminal Block
The Weidmüller LL 5.00/14/90 3.2SN OR BX PCB terminal block is designed for board-level wiring tasks where a higher pole count, dependable screw termination, and efficient right-angle conductor exit are required. In industrial electronics and device manufacturing, a 14-pole board terminal can be especially useful when multiple control, signal, or supply lines need to be grouped into one clear, serviceable terminal section.
Product Overview
This model is a 14-pole printed circuit board terminal block with 5.00 mm pitch, 90-degree conductor outlet direction, 3.2 mm tinned solder pins, and orange housing. It uses a clamping yoke screw connection and is packaged in a box. The Weidmüller LL 5.00/14/90 3.2SN OR BX PCB terminal block is part of the LL family within the OMNIMATE Signal portfolio, making it relevant to industrial board assemblies that value mechanical stability and easy handling.
Technical Features
- Product type: PCB terminal block
- Pitch: 5.00 mm
- Pole count: 14
- Outlet direction: 90°
- Solder pin length: 3.2 mm
- Finish: tinned
- Connection method: clamping yoke connection
- Maximum clamping range: 6 mm²
- IEC rating: 500 V / 32.5 A / 0.5–6 mm²
- UL rating: 300 V / 20 A / AWG 26–12
- Packaging: Box
Why a 14-Pole Board Terminal Is Useful
The 14-pole layout gives designers room to consolidate more circuits into one terminal area without resorting to multiple separate blocks. The Weidmüller LL 5.00/14/90 3.2SN OR BX terminal block can therefore simplify board edge planning, reduce component fragmentation, and support more organized field wiring.
In industrial equipment, this can also make documentation and labelling easier. Installers and service teams usually benefit from a logical one-block terminal arrangement rather than several distributed small terminals.
Handling and Layout Benefits
The clamping yoke screw connection offers dependable conductor retention and long-established service familiarity. This matters in industrial environments where products must remain maintainable over years of use. The right-angle design helps keep wire routing parallel to the PCB, which is advantageous in compact equipment and in applications that require clean internal cable paths.
Because of its conductor capacity, the Weidmüller LL 5.00/14/90 3.2SN OR BX PCB terminal block is suitable for applications that go beyond light-duty signaling and need a more substantial board terminal.
Common Applications
This terminal block may be used in process control devices, machine subassemblies, energy-related electronics, industrial building systems, OEM interface boards, and distributed control electronics. The 14-pole configuration is a good fit where connection density needs to increase while keeping the overall design understandable.
FAQ
What is the Weidmüller LL 5.00/14/90 3.2SN OR BX used for?
It is used for direct wire termination on printed circuit boards in industrial and electronic applications that need 14 connection positions.
Why is 14 poles a practical option?
It allows more circuits to be grouped in one terminal area, which can simplify wiring and reduce the need for multiple separate terminal components.
Is the connection technology easy to service?
Yes. Clamping yoke screw connection is widely recognized and easy for maintenance teams to understand and work with.
Does the 90-degree outlet help in compact devices?
Yes. It supports lateral wire routing, which can make better use of limited enclosure space.
What kind of conductor sizes does it support?
The published data shows support for 0.5 to 6 mm² under IEC and AWG 26 to 12 under UL.
