Weidmüller LL 5.00/08/90 3.2SN OR BX PCB Terminal Block

The Weidmüller LL 5.00/08/90 3.2SN OR BX PCB terminal block is designed for printed circuit board applications that require dependable conductor termination, a practical conductor range, and a layout-friendly right-angle form. In industrial electronics, products in this category are used where field wiring needs to terminate directly on the PCB in a structured and serviceable way. That includes control devices, automation modules, power interface boards, and measurement equipment.

Product Overview

The Weidmüller LL 5.00/08/90 3.2SN OR BX is a PCB terminal block with 8 poles and a 5.00 mm pitch. It features a 90-degree conductor outlet, 3.2 mm solder pin length, tinned contacts, and an orange housing. The product uses clamping yoke screw connection technology, which remains a trusted solution for many industrial board-level applications because it supports secure conductor fastening and familiar maintenance handling.

As a Weidmüller LL 5.00/08/90 3.2SN OR BX PCB terminal block, it naturally aligns with searches for an 8-pole PCB terminal, a 5.00 mm board terminal, or a Weidmüller screw-clamp terminal for industrial PCB use.

Technical Characteristics

  • Product type: PCB terminal block
  • Pitch: 5.00 mm
  • Number of poles: 8
  • Conductor outlet direction: 90°
  • Solder pin length: 3.2 mm
  • Contact finish: tinned
  • Housing colour: orange
  • Connection type: clamping yoke connection
  • Maximum clamping range: 6 mm²
  • IEC rating: 500 V / 32.5 A / 0.5–6 mm²
  • UL rating: 300 V / 20 A / AWG 26–12
  • Packaging: Box

Why an 8-Pole Terminal Block Is a Practical Choice

The 8-pole layout is often selected for boards that need a moderate connection count while maintaining a compact footprint. The Weidmüller LL 5.00/08/90 3.2SN OR BX terminal block is well suited to applications where several control signals, low-voltage supply lines, or grouped functional connections must be organized cleanly on one edge of the PCB.

Instead of using multiple smaller terminals, an 8-pole terminal block can simplify wiring documentation and help reduce component count. In many equipment designs, that contributes to better assembly consistency and a more manageable internal architecture.

Connection and Handling Advantages

The clamping yoke screw connection used in the Weidmüller LL 5.00/08/90 3.2SN OR BX PCB terminal block offers a clear installation process and secure conductor retention. This connection style is especially valued in industrial environments where technicians expect proven mechanical stability and straightforward service access.

The right-angle design is also important in real-world assemblies. By routing conductors parallel to the board, it helps manage enclosure depth and supports more organized cable paths. This is useful in compact housings and densely arranged control cabinets where every millimetre of space can matter.

Weidmüller LL 5.00/08/90 Typical Applications

This terminal block can fit into machine control PCBs, alarm and monitoring modules, signal interface boards, HVAC electronics, building automation controls, and many OEM assemblies where direct PCB wiring is preferred. Its conductor range allows it to handle more demanding board-level terminations than many lighter-duty signal connectors.

Because it belongs to a recognized Weidmüller PCB connection family, it also supports engineering consistency when similar terminal formats are used across multiple devices in one product portfolio.

Weidmüller LL 5.00/08/90 FAQ

What is the Weidmüller LL 5.00/08/90 3.2SN OR BX?

It is an 8-pole PCB terminal block with 5.00 mm pitch, screw connection technology, and a 90-degree conductor outlet.

Why is 5.00 mm pitch important?

This pitch offers a useful balance between conductor capacity, insulation spacing, and board space efficiency in industrial electronics.

Is the screw connection still relevant compared with faster connection systems?

Yes. Screw connection remains highly relevant because it is familiar, dependable, and widely accepted in industrial service practices.

Can this terminal block be used in compact enclosures?

Yes. Its 90-degree layout helps route wires laterally, which can improve space usage inside compact devices.

What conductor sizes can it support?

According to the published data, it supports 0.5 to 6 mm² under IEC and AWG 26 to 12 under UL.

Where can I find related PCB connection products?

For more information about Weidmüller, exploring related PCB terminal and connector families is a useful next step.
