Weidmüller DRI314615LT Relay Overview

The Weidmüller DRI314615LT miniature industrial relay is a D-SERIES DRI component built for compact digital signal switching in industrial automation. Also known as Weidmüller 7760056319 relay, the official product information describes it as a relay for switching, amplifying, and multiplying digital signals with low electrical load in a small design. Supporting product pages identify it as a 1 CO contact version with LED and test button, and one official language variant lists a 115 V AC rated control voltage and a 10 A continuous current rating.

Why the Weidmüller DRI314615LT is practical

The combination of a single changeover contact, visible LED status, and a manual test button makes the Weidmüller DRI314615LT industrial relay a service-friendly choice. In real maintenance situations, the LED helps confirm coil status quickly, while the test button supports manual verification without redesigning the control logic. That improves usability in machine panels, industrial cabinets, and utility-related control assemblies.

Technical profile in context

This relay uses flat blade connections (4.7 mm x 0.5 mm) and belongs to the compact DRI 16 mm width family. The 115 V AC coil variant is relevant in systems that still rely on 115 V AC control architecture rather than 24 V DC or 24 V AC. That makes exact product-code selection especially important, since coil voltage must match the application precisely.

Where it fits best

The Weidmüller 7760056319 relay is suited to compact industrial switching, interface tasks, machine control, and cabinet logic where one changeover contact is enough and manual diagnostics are welcome. For more information about related relay options, visit Weidmüller solutions.

FAQ about the Weidmüller DRI314615LT

What is the Weidmüller DRI314615LT?

It is a miniature industrial relay in the D-SERIES DRI family for compact digital signal switching.

What control voltage does the Weidmüller 7760056319 use?

An official product page lists it as a 115 V AC relay variant.

How many contacts does it have?

The relay is identified as a 1 CO contact version.

Does it include an LED and test button?

Yes. The official product pages identify it as a version with LED and test button.

What current rating is listed?

One official language variant lists a 10 A continuous current rating.

Where is this relay commonly used?

It is commonly used in machine control and compact industrial switching tasks where service-friendly diagnostics are useful.
