Weidmüller DRI314524LT Industrial Relay Guide
The Weidmüller DRI314524LT miniature industrial relay is a D-SERIES DRI relay designed for compact digital signal switching in control environments where space efficiency and practical diagnostics both matter. Also referenced as Weidmüller 7760056318 industrial relay, the product is described as a relay for switching, amplifying, and multiplying digital signals with low electrical load in a small design. Related official pages identify it as a 1 CO contact version with LED and test button.
Why the Weidmüller DRI314524LT is useful
In real industrial cabinets, service visibility can be almost as important as switching performance. The Weidmüller DRI314524LT relay benefits from an LED for quick status feedback and a test button for manual functional checking during commissioning or troubleshooting. That combination helps technicians reduce diagnostic time and adds practical value in machine automation, OEM panels, and utility interface systems.
Technical features that shape application
The relay uses flat blade connections (4.7 mm x 0.5 mm) and belongs to the DRI 16 mm width family. Its compact dimensions make it attractive in dense cabinet layouts, while the single changeover contact suits focused switching and interface tasks without unnecessary complexity. Although the main result snippet does not list the coil voltage directly, the product family and naming indicate the 24 V AC variant represented by this code.
Typical applications
The Weidmüller 7760056318 industrial relay is relevant for digital signal switching, compact control interfaces, and automation tasks where one reliable changeover path is enough. It is particularly appealing in designs that prioritize service-friendly diagnostics through visible status and manual testing. For more information about related D-SERIES products, visit Weidmüller solutions.
FAQ about the Weidmüller DRI314524LT
What is the Weidmüller DRI314524LT?
It is a miniature industrial relay in the D-SERIES DRI family for compact digital signal switching.
How many contacts does the Weidmüller 7760056318 have?
This version is identified as a 1 CO contact relay.
Does it include an LED?
Yes. The official product family page identifies it as a version with LED.
Does it include a test button?
Yes. The relay is listed as a version with LED and test button.
What type of connection does it use?
It uses flat blade connections (4.7 mm x 0.5 mm).
Where is it commonly used?
It is commonly used in compact industrial control panels and interface tasks where service visibility is important.
