Weidmüller DRI314524L Industrial Relay Guide
The Weidmüller DRI314524L miniature industrial relay is a D-SERIES DRI relay developed for compact digital signal switching in industrial control systems. Also referenced as Weidmüller 7760056307 relay, the official product information identifies it as a relay with 1 CO contact AgSnO, a 24 V AC rated control voltage, a 10 A continuous current rating, and flat blade connections (4.7 mm x 0.5 mm). The same listing states that a test button is not available, while related product pages identify it as a version with LED.
Why the Weidmüller DRI314524L is relevant
This relay stands out because it combines a compact form factor with a relatively strong 10 A continuous current rating. That makes the Weidmüller DRI314524L industrial relay attractive in control tasks that need a compact component but still require a more substantial current capability than lighter-duty interface relays provide. The LED adds useful status visibility without adding the extra manual actuation feature of a test button.
Technical value in cabinet design
The 24 V AC coil makes this relay appropriate in installations where AC control logic remains part of the project standard. Its 1 CO contact arrangement suits single-path switching, command transfer, and compact interface logic. Since it belongs to the DRI 16 mm width family, it also supports high-density cabinet layouts where available space is limited.
Common use cases
The Weidmüller 7760056307 relay is suited to machine control, automation panels, utility cabinets, and industrial switching tasks that need a compact 24 V AC relay with visible status indication. For more information about related industrial relay products, visit Weidmüller solutions.
FAQ about the Weidmüller DRI314524L
What is the Weidmüller DRI314524L?
It is a miniature industrial relay in the D-SERIES DRI family.
What is the control voltage of the Weidmüller 7760056307?
The relay is specified with a 24 V AC rated control voltage.
How many contacts does it have?
It has 1 CO contact.
What is the current rating?
The relay is rated for 10 A continuous current.
Does it include a test button?
No. The official listing states that a test button is not available.
Does it include an LED?
Yes. Related product pages identify it as a version with LED.
