Weidmüller 1007040000 Male Header Technical Guide
The Weidmüller 1007040000 male header, designated SL-SMT 5.08HC/11/90LF 3.2SN BK BX SO, is a board-side connector for pluggable PCB systems. It is intended to be soldered onto the PCB and used as the fixed mating side for a corresponding female plug connector. With 11 poles, 5.08 mm pitch, and a 90° configuration, it is especially relevant to industrial layouts where side-oriented connection geometry is preferred.
Users looking for Weidmüller 1007040000 male header, SL-SMT 5.08HC 11-pole header, or 5.08 mm 90 degree PCB male header are usually working on industrial electronics that require both removable connectivity and strong board-side mechanical retention.
Weidmüller 1007040000 Technical characteristics
References for this exact code describe it as a PCB plug-in connector, male header with solder flange, THT/THR solder connection, 5.08 mm pitch, 11 poles, 90° layout, and 3.2 mm solder pin length. The contact finish is listed as tinned, and the housing color is black. Product listings also show this series as part of Weidmüller’s HC header family for higher-current pluggable PCB applications.
Why a board-side header matters
In pluggable PCB systems, the male header is the structural anchor of the connection concept. It defines how the board interfaces with the removable plug and plays a direct role in mating stability, solder retention, and overall serviceability. The Weidmüller 1007040000 male header is therefore more than a simple connector pin row. It is a central part of a modular interconnection strategy.
The THT/THR design is particularly valuable because it supports strong board attachment and can suit manufacturing flows that combine reliable mechanical retention with automated assembly needs.
Why 90° orientation is useful
A 90° male header helps route the mating interface parallel to the PCB surface instead of vertically above it. This is beneficial in compact product housings, side-exit layouts, and equipment where height above the board is limited. In many industrial designs, this can improve enclosure fit and produce a cleaner cable path.
Weidmüller 1007040000 FAQ
What is Weidmüller 1007040000?
It is an 11-pole PCB male header used in pluggable connector systems. It is designed to be mounted on the board and paired with a compatible female plug.
What kind of solder connection does it use?
The product references identify it as using THT/THR solder connection with solder flange support, which is valuable for stable PCB mounting.
Why is a 90° male header important?
It supports side-oriented connection geometry, which is often preferred in compact enclosures or applications where vertical clearance is limited.
What does the HC family positioning suggest?
HC in this connector family points to a higher-current-oriented design approach compared with lighter-duty board connection formats.
Where can this header be used?
It is suitable for industrial control boards, power-related electronics, modular machine assemblies, and PCB designs that use removable plug-in wiring concepts.
For more information about Weidmüller, you can review matching female plugs and related PCB interconnection products.
