Weidmüller 1007001000 Sensor Actuator Cable Guide
The Weidmüller 1007001000 sensor actuator cable, marketed as SAIL-M12BW-4-2L10T, is an industrial M12 cordset intended for longer-distance sensor and actuator wiring. It combines a 4-pole M12 A-coded angled female connector with a 10 meter cable, integrated LED function, and a robust cable construction suited to demanding factory environments.
Users looking for Weidmüller 1007001000 cable, Weidmüller SAIL-M12BW-4-2L10T, or 10 meter M12 sensor cable with LED are usually dealing with installations where standard short patch lengths are not enough and connection reliability must still remain high.
Technical makeup of the product
Product references identify this model as a sensor/actuator line with one free conductor end and one angled M12 female socket. It is 4-pole, A-coded, unshielded, and fitted with LED indication. The cable uses a PUR sheath and belongs to a family of molded and tested cordsets designed for industrial wiring. Relevant documentation also references connector standard IEC 61076-2-101. :contentReference[oaicite:3]{index=3}
Why a 10 meter industrial M12 cable is important
In many automation layouts, long cable runs are unavoidable. Sensors may be positioned along conveyor lines, around safety perimeters, or at remote machine stations. In those cases, the Weidmüller 1007001000 sensor actuator cable offers a ready-to-install solution that avoids the added work of custom cable assembly.
The longer length also supports cleaner project planning because designers can use a standard cordset rather than introducing additional couplings or extension points. Fewer connection points can be beneficial for system clarity and reliability.
Field performance perspective
The molded connector design supports repeatable industrial use, while the PUR sheathing helps with flexibility and wear resistance in machine-related environments. The angled female connector format is useful wherever installation space is limited or cable direction needs to remain controlled at the connection point.
This makes the product a strong option for robotics, process machinery, packaging lines, and distributed automation hardware where sensors and actuators must be wired over longer distances without compromising service visibility.
Weidmüller 1007001000 FAQ
What is Weidmüller 1007001000 used for?
It is used for connecting sensors and actuators in industrial systems, especially where a longer M12 cable run is required between the device and the control side.
What are the main technical highlights?
The product includes a 4-pole angled M12 A-coded female connector, a 10 meter cable, LED indication, PUR sheath, and a molded tested cable assembly design.
Weidmüller 1007001000 Why choose a 10 meter version instead of a shorter one?
A 10 meter cable is useful in larger machines or layouts with longer sensor routing paths. It reduces the need for extra extension points and supports simpler installation planning.
Is this cable intended only for signal transmission?
No. Sensor actuator cables are commonly used for both sensor signals and actuator-related connections in industrial systems, depending on the application design.
Why is the angled connector version beneficial?
It helps control cable direction near the device interface, reduces bending stress in tight spaces, and often fits better in compact machine layouts than a straight connector.
For more information about Weidmüller, you can review additional sensor-actuator connectivity products and M12 cable families.
