Weidmüller 1006650000 6-Pole Male Header Guide
The Weidmüller 1006650000 6-pole male header, designated SL 5.00/06/180B 3.2SN GN BX, is a board-side connector created for pluggable PCB interconnection systems. It is intended to work as the fixed mating interface on the board, allowing a compatible plug connector to be inserted and removed as needed during assembly, service, or replacement.
This is the kind of component often researched under phrases such as Weidmüller 1006650000 male header, 6-pole PCB header connector, or Weidmüller SL 5.00/06/180B 3.2SN GN BX when engineers need a stable and service-friendly board connection point.
Technical characteristics
Weidmüller lists this code as a PCB plug-in connector, male header with dovetails for fixing blocks and THT solder connection. It features a 5.00 mm pitch, 6 poles, a 180° design, and 3.2 mm tinned solder pins. The housing color is pale green. The product data shows IEC ratings of 400 V / 18 A and UL ratings of 300 V / 15 A. Recent references also indicate that this code is discontinued and available until 31 August 2025. :contentReference[oaicite:10]{index=10}
Why a 6-pole male header can be valuable
The 6-pole format creates more room for grouped connections than a 3-pole version, while still remaining reasonably compact for industrial PCB layouts. It is often a good fit for mixed control and auxiliary power lines, grouped signal channels, or other medium-density board interfaces that benefit from a removable plug architecture.
The Weidmüller 1006650000 male header also supports a more orderly service model because the wire-side plug can be disconnected without disturbing the board-side soldered interface. In real maintenance workflows, that can reduce handling risk and simplify replacement tasks.
Board retention and layout logic
Through-hole headers remain important in industrial electronics because they combine reliable soldered retention with a connector structure designed to withstand repeated mating cycles. That is especially relevant for machine controls, equipment modules, and panel-connected electronics that may be serviced over a long operational life.
With its 180° arrangement, the header aligns with connector systems intended for flatter cable routing. That can help support compact equipment design where internal cable paths must stay predictable and manageable.
Lifecycle status and design implications
The fact that this product is marked discontinued should be considered a major engineering detail. If it is already present in an installed platform, accurate documentation remains essential for spare-part assessment, compatibility checks, and any redesign planning. If it is being considered for a new platform, the lifecycle note should be reviewed carefully before specification.
In other words, the Weidmüller SL 5.00/06/180B 3.2SN GN BX male header still matters from a technical perspective even when lifecycle decisions are already shifting.
FAQ
What is Weidmüller 1006650000?
It is a 6-pole male header for PCB plug-in connection systems. It forms the fixed board-side mating interface for compatible pluggable connectors in industrial electronics.
What are the main technical values?
The product data indicates 5.00 mm pitch, 6 poles, 180° design, THT solder connection, 3.2 mm tinned solder pins, IEC ratings of 400 V and 18 A, and UL ratings of 300 V and 15 A.
Why use a male header instead of direct wire termination on the PCB?
A male header supports a pluggable interface. That makes wiring more modular, simplifies service and replacement work, and allows the cable-side plug to be handled separately from the board.
Is this part still active for new designs?
Recent product references indicate that it is discontinued, with availability information pointing to 31 August 2025 as the last order date. This should be taken into account for any new specification work.
Where is a 6-pole male header especially useful?
It is useful in industrial control boards, modular electronics, equipment interfaces, and installations where multiple conductors need to be grouped in a removable connector format without taking excessive board space.
For more information about Weidmüller, you can review related board-side headers and successor-ready connection families.
