Weidmüller 1006530000 Female Plug Connector Overview
The Weidmüller 1006530000 female plug connector, identified as BLT 5.08HC/05/180 SN OR PRT K01, is a 5-pole pluggable PCB connector intended for industrial board connection tasks that require both current capability and straightforward field wiring. It belongs to the BLT 5.08HC product family, a range known for TOP screw connection technology, practical conductor access, and a form factor that suits automation, control electronics, and modular equipment designs.
Many engineers searching for a Weidmüller 1006530000 connector, Weidmüller BLT 5.08HC female plug, or a 5-pole 5.08 mm pluggable terminal block are looking for exactly this balance: strong contact reliability, a familiar 5.08 mm pitch, and a removable wiring concept that simplifies servicing.
Core technical profile
This model is a female plug with 5 positions, 5.08 mm pitch, and a 180° wire entry direction. The connection method is TOP screw connection, which supports practical screwdriver access and secure conductor termination. The product data published for this family shows IEC ratings up to 400 V and 27 A, while UL values are listed at 300 V and 15 A, with conductor support in the 0.2 to 2.5 mm² and AWG 26 to AWG 14 range. The family is also described by Weidmüller as a high-current female plug with space for marking and coding. :contentReference[oaicite:2]{index=2}
Why this 5-pole female plug is relevant
The Weidmüller 1006530000 female plug connector suits projects where designers want a removable wire-side component rather than a fixed board-only interface. In industrial electronics, that matters because field replacement, pre-assembly, and testing are easier when cable assemblies can be disconnected cleanly from the PCB header.
The 5-pole format is especially practical in compact control circuits. It can support grouped signal paths, auxiliary supply lines, or mixed low-count functional wiring without taking more board space than necessary. This makes the connector appropriate for drive electronics, machine control cards, communication interfaces, and compact I/O boards.
How the TOP screw concept helps in the field
One of the more useful aspects of the Weidmüller BLT 5.08HC/05/180 SN OR PRT K01 female plug connector is the TOP screw connection approach. In dense equipment, technicians often work from limited angles, so accessible screw entry can reduce wiring frustration. That does not only improve convenience; it can also help support more consistent termination quality.
Because the product also allows marking and coding within the series concept, it is well aligned with installations where connection clarity and mismatch prevention are important. In real maintenance scenarios, that can save time and lower the risk of human error.
Application perspective
This connector is a sound fit for industrial board systems that need a dependable plug-and-socket style arrangement. It is not simply about making the board removable. It is also about improving assembly flow, enabling organized harness preparation, and keeping service intervention efficient over the life of the equipment.
For engineers comparing a Weidmüller 1006530000 female plug connector against more generic pluggable terminal options, the key differentiators are the established 5.08 mm ecosystem, the high-current orientation of the HC version, and the service-friendly design language.
FAQ
What kind of connector is Weidmüller 1006530000?
It is a 5-pole female plug connector for PCB applications. It belongs to the BLT 5.08HC family and uses a TOP screw connection system with a 180° conductor outlet direction, making it suitable for modular board interconnection in industrial devices.
What does the HC designation indicate?
Within this family, HC refers to a high-current version. That is important because many board connectors are designed mainly for signal-level tasks, whereas this variant is positioned for stronger electrical performance within a pluggable PCB connection format.
What are the main electrical ratings?
The family data for this coded 5-pole version indicates IEC ratings of 400 V and 27 A, with UL values of 300 V and 15 A. Conductor capacity is listed in the range of 0.2 to 2.5 mm² and AWG 26 to AWG 14.
Why choose a 5.08 mm female plug connector?
A 5.08 mm pitch remains a strong standard for industrial electronics because it offers a useful balance between conductor handling comfort and board density. It is large enough for service-friendly wiring, yet still compact enough for many control and interface boards.
Is this connector suitable for maintenance-focused equipment designs?
Yes. The pluggable structure supports easier replacement of wired assemblies and can reduce intervention time during service. For control cabinets, modular machines, and board-based automation products, that can be a very practical benefit.
