Weidmüller 1006310000 Male Plug Connector Technical Guide
The Weidmüller 1006310000 male plug connector, listed as SLS 5.08/08/180FI SN OR BX PRT, is an 8-pole PCB plug-in connector designed for stable board-to-wire interfaces in industrial electronics. It uses a 5.08 mm pitch, a 180° conductor outlet direction, and a tension-clamp connection concept that supports dependable field wiring while keeping the PCB side structured and serviceable.
In practical terms, this product is often relevant when engineers need a Weidmüller SLS 5.08 male plug that balances compact spacing with robust electrical values. For users searching phrases such as Weidmüller 1006310000 connector, Weidmüller SLS 5.08/08/180FI male plug, or 8-pole PCB plug-in connector, this model fits applications where repeatable mating, clean wire routing, and maintenance-friendly replacement matter.
Key technical characteristics
The connector is specified as an 8-pole male plug with 5.08 mm pitch and 180° outlet direction. The connection system is a tension-clamp design, and the stated maximum clamping range reaches 3.31 mm². On the electrical side, Weidmüller lists the product at 400 V / 23 A under IEC data and 300 V / 15 A under UL data, with conductor acceptance from 0.2 to 2.5 mm² and AWG 26 to AWG 12. These values position the product as a serious option for industrial controller boards, interface modules, and power-adjacent signal distribution tasks. :contentReference[oaicite:1]{index=1}
Where this male plug connector fits best
A product like the Weidmüller 1006310000 male plug connector is especially useful in systems that need a removable connection architecture rather than permanent wiring directly on the PCB. In automation devices, control electronics, machine modules, and panel-linked boards, pluggable interfaces simplify assembly and reduce downtime during replacement or service.
The 8-pole layout is another practical advantage. It gives designers enough connection points to group common control circuits, auxiliary power lines, or grouped signals into a single pluggable interface. That usually improves installation clarity and can also support cleaner labeling and more predictable service work.
Why 5.08 mm pitch still matters
There is a reason 5.08 mm pitch remains highly searched and widely used in industrial interconnection. It sits in a useful middle ground: not too dense for technicians to work with, but still compact enough for many control boards. With the Weidmüller SLS 5.08/08/180FI SN OR BX PRT male plug connector, that spacing supports practical conductor handling without making the PCB interface oversized.
For many OEM and maintenance teams, that translates into easier assembly, reduced risk of wiring mistakes, and a more orderly service environment. Those are not abstract benefits. In real projects, easier terminal access and clearer conductor assignment can noticeably improve field efficiency.
Mechanical and maintenance considerations
The 180° outlet direction supports cable routing that runs parallel to the board. That can be helpful in compact housings, shallow control enclosures, and equipment where vertical wire exit would create strain or congestion. Because the connector is pluggable, technicians can disconnect and replace subassemblies without reterminating every conductor from scratch.
That is one reason a Weidmüller 1006310000 male plug connector may be preferred over a fixed arrangement in modular systems. If a board must be exchanged, the mating concept often makes the intervention more predictable and less disruptive.
FAQ
What type of product is Weidmüller 1006310000?
It is a male PCB plug-in connector. More specifically, it is an 8-pole connector in the SLS 5.08 family with 5.08 mm pitch and a 180° conductor outlet. This makes it suitable for modular board interconnection where a pluggable interface is preferred over a permanently wired board edge.
What electrical values are associated with this connector?
According to the product data, the connector is rated at 400 V and 23 A under IEC values, and 300 V and 15 A under UL values. Those figures make it relevant for industrial control and interface boards that require dependable current carrying performance without moving into very large power-terminal formats.
What conductor range can it handle?
The published conductor range is 0.2 to 2.5 mm², with UL wire sizes from AWG 26 to AWG 12. That gives engineers flexibility when working with lighter control conductors or somewhat heavier wiring depending on the surrounding design.
Why would someone choose an 8-pole male plug connector?
An 8-pole format helps consolidate multiple lines into one organized pluggable point. That can simplify PCB layout, reduce connection clutter, and make field service more manageable. In many industrial products, fewer separate connection points also means easier documentation and cleaner wiring practice.
Is the 180° outlet direction useful in compact enclosures?
Yes. A 180° outlet direction often helps when conductors need to travel parallel to the board rather than rising upward. This can improve cable management in slim housings, stacked assemblies, and panel-mounted electronics where space above the board is limited.
