Weidmüller 1003360000 HDC CM BUS F1 CT WLD as a ConCept Module Insert

The Weidmüller 1003360000 HDC CM BUS F1 CT WLD is a modular insert for heavy-duty connector systems. In connector engineering, modularity is increasingly important because machine builders and integrators want more flexible interface layouts without having to redesign the entire housing concept. The Weidmüller HDC CM BUS F1 CT WLD sits in that modular thinking: it is part of the ConCept module system for heavy-duty connectors.

This product is listed as an HDC insert, ConCept module. The official product data identifies dimensions of approximately 18.5 mm depth, 47.5 mm height, and 13.5 mm width, along with a net weight of 29 g. It also carries a UL 94 V-0 flammability rating, low smoke compliance according to DIN EN 45545-2, and a durability rating of at least 500 plugging cycles.

What the Weidmüller HDC CM BUS F1 CT WLD Is Meant For

The Weidmüller 1003360000 ConCept module insert is intended for modular heavy-duty connector assemblies where the interface needs to be configured more precisely than a fixed insert would allow. This kind of module architecture is useful when power, signal, data, or special transmission functions must be arranged in a more application-specific way within the same overall connector family.

That flexibility is increasingly valuable in industrial automation, transport-related equipment, modular machines, and systems that evolve over time. Instead of replacing a complete connector architecture, engineers can adapt specific module positions as needed.

Technical Characteristics of the Weidmüller 1003360000

The product belongs to the ConCept module series in the heavy-duty connector portfolio. It has a compact width of 13.5 mm, which helps support dense modular arrangements. The listed material behavior includes UL 94 V-0, and the module is identified as low smoke according to DIN EN 45545-2. That is particularly relevant in applications where fire behavior and smoke development are part of the specification landscape, including transport-related and enclosed-system environments.

The module is also specified for at least 500 plugging cycles, a useful figure for systems where connectors are not only installed once but may be disconnected and reconnected throughout the service life.

Why Modular HDC Inserts Are Valuable

Traditional fixed inserts work well when the application stays constant. Modular inserts are stronger where interface requirements vary. The Weidmüller 1003360000 HDC CM BUS F1 CT WLD supports a more configurable approach, allowing engineers to tailor connector internals more precisely to the task at hand.

This is especially helpful in platforms that are offered in several machine variants. A modular connector approach can simplify product family design, reduce redesign effort, and improve service logic by keeping the external housing concept consistent.

Application Areas

The product is relevant in heavy-duty industrial connectors used in machine building, transport systems, modular automation equipment, and advanced industrial interconnect layouts where a modular insert strategy is preferred.

For more information about Weidmüller, the broader ConCept module family is worth reviewing alongside compatible housings and carrier systems.

FAQ

What is the Weidmüller 1003360000 HDC CM BUS F1 CT WLD?

It is a heavy-duty connector ConCept module insert used in modular HDC connector assemblies.

What are the dimensions of the product?

The listed dimensions are approximately 18.5 mm depth, 47.5 mm height, and 13.5 mm width.

How many plugging cycles is the module rated for?

The module is specified for at least 500 plugging cycles.

What flammability rating is associated with this product?

The listed flammability rating is UL 94 V-0.

Why is low-smoke compliance relevant here?

Low-smoke performance can matter in enclosed industrial systems and transport-related applications where fire behavior requirements are stricter.

Where is the Weidmüller HDC CM BUS F1 CT WLD commonly used?

It is commonly used in modular heavy-duty connector systems for machinery, automation, and transport-oriented industrial applications.
