Weidmüller 1003060000 HDC HQP AWLU Angled Bulkhead Housing
The Weidmüller 1003060000 HDC HQP AWLU angled bulkhead housing is designed for industrial connector layouts where standard straight panel interfaces are not always the best fit. In machine building and industrial automation, limited installation depth, cable routing direction, and service access often influence connector housing choice. That is why terms like angled bulkhead housing, compact heavy duty connector housing, HQ connector enclosure, and Weidmüller HDC HQP AWLU attract strong engineering interest.
What Kind of Housing Is the HDC HQP AWLU?
The Weidmüller HDC HQP AWLU is an angled bulkhead housing in the HQ size. It is described as a standard bulkhead housing with side-locking clamp on the lower side and IP65 protection in the plugged condition. Because it is an angled version, it helps designers manage geometry more effectively where enclosure clearances, wall spacing, or cable routing paths make a conventional form less practical.
Technical Profile and Dimensions
The official data for the Weidmüller 1003060000 HDC HQP AWLU shows a compact but taller profile than a simple straight bulkhead model. It features a housing height of about 55 mm, total length of 46 mm, housing width of 33 mm, and an angled cable-entry geometry even though the product itself is listed with no cable glands and no sealing for cable entries. It is part of the plastic housing line, uses the HQ installation size, and is identified with UL 94 V-0 flammability.
Why an Angled Bulkhead Housing Can Be Useful
Angled housings are often chosen for a practical reason rather than a purely electrical one: they help adapt the connector system to the physical design of the machine. In tightly packed equipment, the difference between a straight housing and an angled housing can affect cable bend radius, assembly comfort, and future service access. The Weidmüller HDC HQP AWLU angled bulkhead housing is particularly relevant when teams need an HQ-format interface that supports better installation ergonomics without moving away from the heavy-duty connector family already defined in the project.
Material and Environmental Positioning
This model is specified as a plastic housing with a side-locking system and is rated IP65 in the plugged condition. In many industrial settings, that combination supports applications where the connector must remain compact, corrosion-aware, and practical to integrate into panel boundaries or machine structures. Weidmüller also notes installation care around correct gasket seating, which is an important reminder that sealing performance depends on assembly quality as much as on product rating.
Typical Use Cases
The Weidmüller 1003060000 HDC HQP AWLU makes sense in modular machinery, packaging systems, industrial handling equipment, and control interfaces where an angled connector outlet improves system layout. It may also be useful when service technicians need clearer access in narrow machine zones. In such cases, housing geometry becomes a real design asset rather than a secondary detail.
When comparing HQ-series options, this product offers a specific advantage: it helps solve physical routing constraints while staying within the broader RockStar® architecture. For More information about Weidmüller, reviewing counterpart housings and insert compatibility is a sensible next step in technical planning.
FAQ
What is special about Weidmüller 1003060000?
Its main distinction is that it is an angled bulkhead housing, which can improve cable routing and installation access in compact machine or panel layouts.
Is the HDC HQP AWLU part of the HQ series?
Yes. The product is specified in HQ installation size, making it part of the compact RockStar® HQ heavy-duty connector housing family.
What protection level does it provide?
It is rated IP65 in the plugged condition, which is important for many industrial environments where dust and water exposure are expected during normal operation.
Is it a plastic or metal housing?
The Weidmüller HDC HQP AWLU belongs to the plastic housing version of the HQ family.
When should an angled bulkhead housing be preferred?
It is usually preferred when space is restricted, cable direction needs to be controlled more carefully, or maintenance access would be improved by an angled connector orientation rather than a straight layout.
