Weidmüller 1002950000 HDC C HX BM1.5AG Female Contact Guide
The Weidmüller 1002950000 HDC C HX BM1.5AG crimp contact is a female contact element for industrial heavy-duty connector systems where stable connection quality and exact system compatibility are essential. In real connector applications, gender selection is just as important as conductor size. The wrong contact cannot be corrected by installation skill alone. That is why the Weidmüller HDC C HX BM1.5AG 1002950000 female crimp contact is specified and sourced by exact code in professional industrial work.
Product Type and Function
This product is a female crimp contact for the Weidmüller heavy-duty connector portfolio and belongs to the MixMate system. It is intended for 1.5 mm² conductors, uses a 4 mm contact diameter, and is made from turned copper alloy with a silver-plated surface. The contact is designed to connect a conductor to an industrial connector in a controlled and repeatable manner.
Weidmüller 1002950000 Why Female Contacts Matter in Connector Design
In heavy-duty connector systems, contact gender is central to the mating structure. A female contact is not simply the opposite of a male contact. It is a defined functional element with its own geometry, mating behavior, and assembly logic. The Weidmüller 1002950000 HDC C HX BM1.5AG female heavy-duty connector contact plays that exact role within compatible MixMate inserts and connector configurations.
Technical Characteristics
The contact is specified for 1.5 mm² conductor cross-section, supports at least 500 plugging cycles, and lists volume resistance of ≤1 mΩ. It also uses an 8 mm stripping length, which is a practical preparation detail for assembly teams. These values matter because repeatable connector performance depends on correct preparation, correct tooling, and the correct contact specification.
Weidmüller 1002950000 Why Material and Finish Count
The use of copper alloy supports suitable conductivity and mechanical properties, while silver plating is a standard industrial choice for contact reliability. In demanding applications, connector contacts must maintain both electrical continuity and mating quality over time. Material selection is one of the reasons this remains achievable.
Where This Contact Is Commonly Used
The Weidmüller HDC C HX BM1.5AG 1002950000 female crimp contact is used in heavy-duty connector assemblies for automation equipment, machinery, modular systems, and industrial connection interfaces where exact conductor size and gender matching are necessary. It is especially relevant in serviceable connectors that may be assembled, maintained, or replaced over the lifecycle of the equipment.
Weidmüller 1002950000 FAQ
What is the Weidmüller 1002950000 HDC C HX BM1.5AG?
It is a female crimp contact for 1.5 mm² conductors within the Weidmüller MixMate heavy-duty connector system.
Why does female contact selection matter?
Because connector systems depend on correct male-female pairing. Using the correct gender is essential for proper mating and electrical function.
What industries use this type of contact?
It is commonly used in machine building, factory automation, modular equipment, and industrial connector-based wiring systems.
Why is the exact conductor size important?
The conductor size must match the contact design to achieve the intended crimp result, mechanical retention, and electrical performance.
Can this contact be treated as a universal replacement?
No. It should be used only where the connector system, gender, conductor size, and tooling requirements match the product specification.
What should be reviewed before assembly?
Review conductor size, stripping length, insert compatibility, correct crimp tool, and the mating architecture of the overall connector system.
