Weidmüller 1002920000 HDC C HX SM2.5AG Technical Contact Guide
The Weidmüller 1002920000 HDC C HX SM2.5AG crimp contact is part of the heavy-duty connector ecosystem where precision, conductor fit, and dependable mating performance are essential. In many industrial installations, the reliability of a connector assembly depends not only on the housing or insert, but on the exact contact selected for the conductor size and operating conditions. The Weidmüller HDC C HX SM2.5AG 1002920000 male crimp contact answers that need with a clearly defined specification for 2.5 mm² conductors.
Product Definition
This product is a male crimp contact for heavy-duty connectors and belongs to the MixMate system. It is intended for a 2.5 mm² conductor cross-section, uses a 4 mm contact diameter, and is made from copper alloy with a silver-plated surface. The contact is produced as a turned contact, which supports dimensional consistency and robust connection behavior.
Why 2.5 mm² Contacts Matter
The 2.5 mm² conductor range is extremely common in industrial wiring. It is often used where signal and control must be combined with practical current-carrying capacity in machines, control interfaces, and modular equipment connections. Because of this, the Weidmüller 1002920000 HDC C HX SM2.5AG heavy-duty connector crimp contact sits in a very practical specification zone for day-to-day industrial design.
Weidmüller 1002920000 Performance Considerations
The product supports at least 500 plugging cycles and specifies volume resistance of ≤1 mΩ. Those figures matter because industrial connectors must maintain dependable performance across repeated mating operations and operational vibration. When a correctly sized conductor is crimped with the correct tool, the result is a mechanically strong and electrically stable connection concept.
The Weidmüller HDC C HX SM2.5AG 1002920000 crimp contact also uses an 8 mm stripping length, which is another practical detail engineers and technicians need when standardizing assembly procedures.
Where This Contact Is Used
This contact is relevant for machine building, modular automation equipment, robotics interfaces, industrial power and signal distribution, and heavy-duty connector inserts that use MixMate architecture. Engineers often choose precise crimp contacts like this one because connector systems are only reliable when every subcomponent is matched correctly.
Weidmüller 1002920000 Why Exact Product Matching Matters
In a connector family with multiple sizes, genders, and conductor ranges, exact part selection is critical. A mismatch at the contact level can affect crimp quality, mating performance, and long-term reliability. That is why the search phrase Weidmüller 1002920000 HDC C HX SM2.5AG male crimp contact is much more useful in practice than a generic product description.
Weidmüller 1002920000 FAQ
What is the Weidmüller 1002920000 HDC C HX SM2.5AG used for?
It is used as a male crimp contact for 2.5 mm² conductors in heavy-duty industrial connector systems.
Why is 2.5 mm² an important conductor size?
Because 2.5 mm² is widely used in industrial wiring for control, interface, and moderate power tasks, making it one of the most practical contact sizes in connector applications.
What does MixMate mean here?
MixMate refers to a connector concept that allows flexible combinations of contact modules or connection types within heavy-duty connector systems.
Why does the production method matter?
A turned contact is valued for its precision geometry and consistent mating characteristics, which support reliable connector performance.
Weidmüller 1002920000 What should installers verify before assembly?
They should verify conductor cross-section, correct crimp tool selection, stripping length, insert compatibility, and the required male or female contact type.
Weidmüller 1002920000 Is this product intended for generic terminals?
No. It is specifically intended for heavy-duty connector systems and should be used within the correct compatible connector architecture.
Weidmüller 1002920000 For more information about Weidmüller, you can explore compatible HDC inserts and accessories.
