Weidmüller 1002440000 BLF 5.08HC/18/90LR SN OR BX Technical Overview
The Weidmüller 1002440000 BLF 5.08HC/18/90LR SN OR BX PCB plug-in connector is an 18-pole female plug built for industrial electronics that need a high-density, single-row connection interface. As part of the OMNIMATE Signal BL/SL 5.08 series, it features a 5.08 mm pitch, a 90-degree conductor outlet, and PUSH IN with actuator technology. This type of connector is especially useful in equipment where many conductors must remain grouped, identifiable, and easy to disconnect during maintenance.
Why the 18-Pole Format Makes Sense
The Weidmüller BLF 5.08HC/18/90LR SN OR BX connector helps engineers manage larger conductor sets without breaking the design into several separate interfaces. This can improve layout discipline and reduce wiring complexity, particularly in automation, machine electronics, and communication hardware.
In service environments, that clearer structure matters. When conductors remain in one labeled pluggable interface, troubleshooting is often faster and more reliable.
Practical Installation Benefits
PUSH IN with actuator supports faster conductor handling and a more controlled release process. For production teams, that helps streamline assembly. For field technicians, it creates a more predictable and user-friendly maintenance experience.
The right-angle outlet further improves usability by helping conductors follow a flatter path. In compact housings, this can reduce congestion and make the internal device layout easier to manage.
Where This Connector Fits Best
The Weidmüller 1002440000 connector is relevant for controller boards, machine interfaces, industrial communication devices, OEM electronics, and distributed automation products where eighteen conductors should remain grouped in one removable interface.
It is also useful in product platforms that benefit from connector-family consistency. Using related pole-count versions from the same family supports smoother engineering and documentation processes.
FAQ
What is Weidmüller 1002440000?
It is an 18-pole female PCB plug-in connector for industrial field wiring and removable PCB connectivity.
Weidmüller 1002440000 Why choose an 18-pole connector?
It lets designers keep many conductors in one organized interface, which can simplify both layout and maintenance.
Weidmüller 1002440000 What does PUSH IN with actuator help with?
It helps with quick conductor insertion and easier release during servicing.
Why is the 90-degree outlet useful?
It supports cleaner cable routing and better use of limited enclosure space.
Weidmüller 1002440000 Is it suitable for industrial control equipment?
Yes. It is well suited to automation, control, interface, and machine electronics.
Weidmüller 1002440000 For more information, visit more about Weidmüller.
