Weidmüller 1002400000 BLF 5.08HC/14/90LR SN OR BX Technical Overview
The Weidmüller 1002400000 BLF 5.08HC/14/90LR SN OR BX PCB plug-in connector is a 14-pole female plug built for industrial electronics that require a larger number of field conductors to be handled in one organized, pluggable interface. As part of the OMNIMATE Signal BL/SL 5.08 family, it uses a 5.08 mm pitch, a 90-degree conductor outlet, and PUSH IN spring connection with actuator. This makes it especially suitable for compact control systems, machine electronics, and interface boards where installation speed and serviceability both matter.
Why the 14-Pole Version Is a Practical Option
The Weidmüller BLF 5.08HC/14/90LR SN OR BX connector is ideal for designs where the conductor count is too high for smaller variants but should still remain within a clean single-row format. Fourteen poles offer enough capacity for grouped signals, power-control combinations, and broader interface layouts without pushing the PCB into a fragmented connection architecture.
In practical engineering work, that often means a neater board design and a more intuitive service concept. One connector body handling fourteen conductors is usually easier to label and easier to troubleshoot than several smaller connectors spread across the assembly.
Installation and Handling Benefits
PUSH IN with actuator is one of the strongest functional benefits of this connector family. It supports fast conductor insertion and a straightforward release process. For production teams, that means more efficient assembly. For maintenance teams, it means predictable handling even after the product has been in operation for a long time.
The 90-degree outlet improves mechanical integration as well. In space-sensitive enclosures, right-angle conductor exit helps wires follow a flatter path, which often improves internal order and reduces unnecessary stress around the connection zone.
Weidmüller 1002400000 What Makes This Connector Family Widely Used
The Weidmüller 1002400000 connector belongs to a family known for secure contact behavior, wide clamping capability, intuitive handling, and pluggable service convenience. These qualities are especially valuable in industrial products where installation quality, uptime, and service efficiency all affect long-term operating cost.
The connector is also appropriate for manufacturers who want consistency across different designs. Using the same connector family across several pole counts helps create continuity in engineering standards, assembly procedures, and field documentation.
Electrical and Application Perspective
A 14-pole PCB plug-in connector can support applications such as industrial control boards, automation nodes, signal distribution electronics, modular machine assemblies, communication hardware, and specialized OEM devices. The 14-pole format provides more conductor capacity without automatically forcing the designer into oversized mechanical solutions.
This balance between capacity and usability is what makes the product attractive. It gives design teams enough room for complex wiring while keeping the final interface manageable for installers and service personnel.
Weidmüller 1002400000 FAQ
What is the main use of Weidmüller 1002400000?
It is used as a 14-pole female PCB plug-in connector for industrial field wiring and removable board-level connectivity.
Why choose a 14-pole connector?
A 14-pole connector is useful when a design requires a relatively high number of conductors in one centralized and service-friendly interface.
Does PUSH IN with actuator reduce installation time?
Yes. It supports quick conductor insertion and practical handling, which can improve assembly efficiency.
Why is the 90-degree conductor outlet helpful?
It helps create more organized internal wiring, especially in shallow or compact housings where cable routing space is limited.
Is this connector suitable for machine and automation systems?
Yes. It is highly relevant for automation, control, interface, and industrial electronics applications.
Can one larger connector improve servicing?
In many cases, yes. A single clearly labeled plug-in interface is often easier to inspect, disconnect, and reconnect than several smaller ones.
Weidmüller 1002400000 For more information, visit more about Weidmüller.
