Weidmüller 1002360000 BLF 5.08HC/10/90LR SN OR BX Technical Overview
The Weidmüller 1002360000 BLF 5.08HC/10/90LR SN OR BX PCB plug-in connector is a 10-pole female plug intended for dependable board-level field wiring in industrial electronics. It is part of the OMNIMATE Signal BL/SL 5.08 series and features a 5.08 mm pitch, a 90° conductor outlet, and PUSH IN with actuator connection technology. This version is specified with a maximum clamping range of 3.31 mm² and electrical values up to 400 V / 24 A under IEC and 300 V / 18.5 A under UL, making it a practical choice for structured multi-conductor interfaces.
Why the Weidmüller 1002360000 Is a Practical Connector Choice
The Weidmüller BLF 5.08HC/10/90LR SN OR BX connector is designed for situations where ten conductors must be grouped in a single removable connection interface. This is especially useful in automation devices, compact control boards, communication equipment, signal distribution modules, and OEM electronics where serviceability is just as important as connection density.
Using one 10-pole connector instead of several smaller plug-in points can improve the overall wiring concept. It keeps conductor groups together, supports clearer labeling, and can make field troubleshooting easier. In a maintenance setting, simplicity often translates directly into shorter intervention times and fewer mistakes.
Connection Technology and User Experience
The connector uses PUSH IN spring connection with actuator, a format appreciated for its speed and ease of use. Installers can work more efficiently, while service technicians benefit from predictable handling during inspection or replacement. That matters because connectors in industrial equipment are rarely touched only once. They must remain practical across the entire lifecycle of the device.
Weidmüller also positions this product family around several functional benefits, including secure and durable contact behavior, high vibration resistance, quick and intuitive operation, wide clamping range, self-locking plug-in behavior, and low-stress unlocking. These are relevant characteristics for industrial equipment that operates in demanding mechanical and operational environments.
Why a 10-Pole Plug-In Connector Can Improve Design Efficiency
A 10-pole PCB plug-in connector offers substantial conductor capacity in one single-row format. That makes it attractive for devices with more complex control schemes or broader signal groupings. Rather than fragmenting the wiring architecture, the connector allows the designer to preserve structure and maintain a clean system layout.
This is particularly useful in products with modular service concepts. When an electronic assembly needs to be replaced or upgraded, a plug-in connection can make the process more manageable. The user or technician can disconnect the wiring interface in a more organized way, without disturbing every conductor individually on the board.
Electrical and Mechanical Context
The Weidmüller 1002360000 BLF 5.08HC/10/90LR SN OR BX supports conductors up to 2.5 mm² and fits the familiar BLF 5.08HC platform with 5.08 mm pitch and a 90-degree cable exit. This makes it compatible with many industrial wiring practices where both space efficiency and practical conductor access are important.
The 90-degree orientation supports flatter wire routing along the PCB or enclosure wall. In compact housings, that can reduce congestion and make the surrounding components easier to reach. Over time, organized wiring also tends to support better maintenance quality because technicians can see and identify the connection paths more clearly.
Typical Areas of Use
The Weidmüller BLF 5.08HC/10/90LR SN OR BX female plug connector is relevant for machine electronics, industrial I/O modules, HVAC controllers, device interface boards, compact power and signal distribution assemblies, and automation equipment that needs a 10-position pluggable field connection.
It is also a strong fit for manufacturers that want connector-family consistency across multiple products. Standardizing on a familiar connection system can simplify assembly procedures, procurement planning, and technical documentation across an entire product portfolio.
FAQ
What is the main purpose of the Weidmüller 1002360000 connector?
It is used as a 10-pole pluggable PCB interface for industrial field wiring, especially where structured multi-conductor connections are needed.
Why is a 10-pole connector useful in industrial electronics?
A 10-pole connector can consolidate multiple conductors into one organized interface, which often improves layout clarity and simplifies maintenance.
Does PUSH IN technology make installation easier?
Yes. PUSH IN with actuator is valued because it supports fast conductor insertion and practical release during service work.
Is the 90-degree conductor outlet important?
Yes. It helps route wires in a flatter path, which can improve cable management inside compact housings and make internal layouts more accessible.
Can this connector be used in automation and control applications?
Yes. Its pole count, electrical ratings, and industrial connection style make it highly relevant for automation, control, and interface assemblies.
Does a pluggable connector reduce maintenance effort?
In many cases, yes. Pluggable connectors can shorten replacement time and reduce the amount of rewiring needed during servicing.
Is this product part of the OMNIMATE Signal family?
Yes. It belongs to the Weidmüller OMNIMATE Signal BL/SL 5.08 connector family.
Weidmüller 1002360000 For more information, visit more about Weidmüller.
