Weidmüller 1002160000 PCB Plug Connector: Technical Overview for Industrial PCB Systems
The Weidmüller 1002160000 PCB plug connector, formally named Weidmüller BLF 5.08HC/09/90F SN OR BX female plug connector, is a 9-pole pluggable connector intended for industrial applications that require structured multi-circuit wire-to-board connectivity. It offers a practical balance of compact design, removable connection functionality, and reliable electrical performance.
This product uses a 5.08 mm pitch and a 90° outlet direction. It is based on PUSH IN with actuator connection technology, which supports intuitive wire insertion and service-friendly handling. That makes it suitable for products where both assembly efficiency and long-term maintenance matter.
Technical Specifications of Weidmüller 1002160000
The Weidmüller 1002160000 female PCB connector is rated at 400 V / 24 A under IEC and 300 V / 18.5 A under UL. It supports conductor sizes of 0.2 to 2.5 mm² and AWG 26 to AWG 12, with a maximum clamping range of 3.31 mm². The housing color is orange, and the product is delivered in box packaging.
These technical details place the connector firmly in the industrial PCB category. Designers searching for Weidmüller 1002160000 PCB plug connector, Weidmüller 1002160000 female plug, or 9 pole 5.08 mm PCB connector are usually looking for exactly this type of reliable pluggable interface.
Why a 9-Pole Connector Can Be a Smart Choice
A 9-pole PCB connector is often selected when grouped I/O, mixed signal circuits, or moderate-density board wiring must stay centralized. This makes it suitable for industrial interface boards, compact machine controllers, automation subassemblies, and monitoring units.
The Weidmüller BLF 5.08HC/09/90F SN OR BX connector supports this kind of design well because it combines sufficient pole count with a removable connection concept. That makes both assembly and service more manageable.
Real-World Design Advantages
In practical enclosures, the 90° outlet direction helps maintain clean cable routing and reduces strain caused by awkward wire bends. PUSH IN with actuator technology also supports efficient conductor handling, which is valuable both on the production floor and during field maintenance.
For industrial product teams, this means the connector contributes not only to electrical connection quality but also to usability across the product lifecycle. That operational value is often overlooked, but it matters greatly in real applications.
FAQ: Weidmüller 1002160000 PCB Plug Connector
What is the Weidmüller 1002160000 used for?
It is used as a 9-pole pluggable wire-to-board connector in industrial PCBs and modular devices.
What is the pitch of the connector?
The pitch is 5.08 mm.
What are the voltage and current ratings?
It is rated at 400 V / 24 A under IEC and 300 V / 18.5 A under UL.
Which wire sizes are supported?
The connector supports 0.2 to 2.5 mm² and AWG 26 to AWG 12.
Why is the 9-pole format useful?
It provides enough positions for grouped circuits without becoming too large for compact board layouts.
Where is the connector commonly applied?
It is commonly used in interface boards, machine electronics, automation modules, and control systems requiring removable connectivity.
