Weidmüller 1002150000 PCB Plug Connector: A Strong Fit for Compact Industrial Wiring
The Weidmüller 1002150000 PCB plug connector, identified as Weidmüller BLF 5.08HC/08/90F SN OR BX female plug connector, is an 8-pole pluggable PCB connector intended for industrial electronics that need a removable wire-to-board interface with dependable electrical and mechanical performance. It is particularly suitable where multiple related conductors must be grouped neatly in one accessible connection area.
This product uses a 5.08 mm pitch and 90° outlet direction, and it relies on PUSH IN with actuator technology for intuitive conductor handling. That makes it useful in compact equipment where installation speed, service access, and controlled cable routing all matter.
Technical Specifications of Weidmüller 1002150000
The Weidmüller 1002150000 female plug connector is rated at 400 V / 24 A under IEC and 300 V / 18.5 A under UL. It supports wire sizes of 0.2 to 2.5 mm² and AWG 26 to AWG 12, with a maximum clamping range of 3.31 mm². Product data also shows dimensions such as a width of approximately 50.44 mm, reflecting the larger pole count. The housing is orange, and the product is packaged in a box.
These specifications make the connector suitable for many industrial boards where a medium-to-higher pole count is needed. Searches like Weidmüller 1002150000 PCB plug connector, Weidmüller 1002150000 female plug, or 8 pole 5.08 mm PCB connector align well with the product’s real-world selection criteria.
Where an 8-Pole Connector Is Commonly Used
An 8-pole pluggable PCB connector is often chosen for grouped control wiring, multiple sensor channels, mixed signal circuits, and modular automation assemblies. It provides more circuit capacity while still keeping wiring understandable and compact.
The Weidmüller BLF 5.08HC/08/90F SN OR BX connector is also a good fit for equipment that may need field servicing. The pluggable design supports easier board replacement or test access, which can be valuable in industrial maintenance scenarios.
Advantages for Engineers and Technicians
The connector supports efficient wiring thanks to PUSH IN technology, and the actuator improves handling during conductor release. The right-angle outlet direction also helps route cables more cleanly inside enclosures. Together, these features create a connector that feels well matched to real industrial work rather than just laboratory specifications.
For OEMs developing compact control products, that balance of usability, density, and reliable connection performance is highly relevant.
FAQ: Weidmüller 1002150000 PCB Plug Connector
What is the Weidmüller 1002150000?
It is an 8-pole female PCB plug connector designed for pluggable industrial wire-to-board connectivity.
What is the pitch of the connector?
The connector uses a 5.08 mm pitch.
What are the key ratings?
It is rated 400 V / 24 A under IEC and 300 V / 18.5 A under UL conditions.
Which wire sizes are supported?
It supports 0.2 to 2.5 mm² conductors and AWG 26 to AWG 12.
Why is a pluggable 8-pole connector useful?
It allows multiple circuits to be grouped on one removable connector, supporting organized wiring and easier servicing.
Where is the Weidmüller 1002150000 typically used?
It is commonly used in automation modules, control boards, instrumentation systems, and building electronics.
