Weidmüller 1002120000 PCB Plug Connector: Ratings, Benefits, and Applications
The Weidmüller 1002120000 PCB plug connector, described as Weidmüller BLF 5.08HC/05/90F SN OR BX female plug connector, is a 5-pole pluggable PCB connector built for industrial wire-to-board connectivity. It is a practical option for systems that need a removable connection point, dependable conductor retention, and straightforward handling during installation and maintenance.
This connector is based on a 5.08 mm pitch platform and uses a 90° wire outlet with PUSH IN with actuator technology. In real applications, this means technicians benefit from quicker conductor insertion and controlled wire routing inside compact enclosures or modular industrial devices.
Technical Specifications of Weidmüller 1002120000
The Weidmüller 1002120000 female PCB plug connector is rated at 400 V / 24 A under IEC and 300 V / 18.5 A under UL. It supports conductor sizes from 0.2 to 2.5 mm² and AWG 26 to AWG 12, with a maximum clamping range of 3.31 mm². The housing is orange, and the unit is supplied in box packaging.
These values make the connector suitable for compact industrial boards that still require strong and stable connection performance. Engineers often search for terms such as Weidmüller 1002120000 PCB plug connector, Weidmüller 1002120000 female plug connector, and 5 pole PCB connector 5.08 mm when they need a reliable pluggable interface in this exact category.
Why a 5-Pole Pluggable Connector Is Useful
A 5-pole PCB plug connector is commonly used where several related conductors must be grouped neatly on one board interface. This may include sensor clusters, signal-reference-earth layouts, controller interfaces, or small industrial subsystem connections. The five-pole format is flexible enough to support practical grouping while staying compact.
The Weidmüller BLF 5.08HC/05/90F SN OR BX connector is especially relevant in modular assemblies where the removable plug concept improves servicing. When electronics need to be replaced or tested quickly, pluggable connectivity can reduce downtime and simplify handling.
Industrial Design Considerations
Because the connector routes wires at 90°, it helps keep cable paths orderly within limited housing depth. The PUSH IN with actuator design also aligns well with modern industrial assembly methods, where speed and repeatability are important. These practical benefits often influence component selection as much as the electrical rating itself.
For designers working on industrial control boards, test interfaces, or building automation electronics, this connector offers a strong balance between compactness, usability, and field service convenience.
FAQ: Weidmüller 1002120000 PCB Plug Connector
What is the Weidmüller 1002120000?
It is a 5-pole female PCB plug connector with 5.08 mm pitch and PUSH IN with actuator technology.
What electrical ratings apply to the connector?
The connector is rated 400 V / 24 A under IEC and 300 V / 18.5 A under UL conditions.
What wire sizes can be connected?
It supports 0.2 to 2.5 mm² conductors and AWG 26 to AWG 12 wires.
What is the benefit of PUSH IN with actuator?
It enables quick insertion and practical release handling, supporting efficient installation and maintenance.
What applications suit a 5-pole connector?
Typical uses include grouped control signals, small power-and-signal interfaces, compact automation modules, and modular electronics.
Why is the 90° outlet useful?
It improves cable routing by allowing wires to run parallel to the PCB, which is valuable in compact industrial enclosures.
For more information about Weidmüller, explore the broader PCB connector portfolio.
