Weidmüller 1002090000 PCB Plug Connector: Technical Overview and Use Cases
The Weidmüller 1002090000 PCB plug connector, listed as Weidmüller BLF 5.08HC/02/90F SN OR BX female plug connector, is a compact pluggable connection component developed for dependable wire-to-board interfaces in industrial electronics. As a 2-pole PCB plug connector, it is especially relevant for low-channel-count control signals, compact power connections, and modular board designs where reliability and easy handling matter as much as electrical performance.
This product belongs to the OMNIMATE Signal family and uses a 5.08 mm pitch with a 90° outlet direction. It features a PUSH IN connection with actuator, which makes wiring intuitive while still supporting a durable and vibration-resistant contact concept. In practical engineering terms, this allows installers to work faster while maintaining connection quality in demanding industrial environments.
Technical Features of the Weidmüller 1002090000 Female Plug Connector
The Weidmüller 1002090000 female plug connector is rated at 400 V / 24 A under IEC conditions and 300 V / 18.5 A under UL conditions. The conductor range is listed as 0.2 to 2.5 mm² under IEC and AWG 26 to AWG 12 under UL. The maximum clamping range is 3.31 mm², and the product is supplied in orange box packaging.
These specifications make the connector suitable for many industrial board-level applications where a compact pluggable terminal is required. Designers often search for parts like Weidmüller 1002090000 PCB plug connector, Weidmüller 1002090000 female plug, or 2 pole 5.08 mm PCB connector when building or servicing modular electronics. This product fits naturally into those search and specification patterns.
Where a 2-Pole PCB Plug Connector Works Best
A 2-pole pluggable PCB connector is often used where simplicity and space efficiency are important. Typical applications include sensor interfaces, small actuator outputs, compact power distribution on a PCB, test equipment, signal conversion boards, and industrial auxiliary circuits. In these use cases, a low pole count is often preferred because it keeps wiring clear and minimizes space consumption.
The Weidmüller BLF 5.08HC/02/90F SN OR BX PCB plug connector is also useful in modular designs where the connector must be removable for servicing or replacement. This is one of the reasons pluggable PCB connectivity remains highly relevant in control panels, machine electronics, and building automation products.
Design Benefits in Industrial PCB Layouts
Because the connector uses a 90° wire outlet, it helps route conductors parallel to the board. This can improve enclosure organization and reduce unnecessary wire bending in compact housings. The PUSH IN connection with actuator also supports quick conductor insertion, which can reduce assembly time in production environments and improve service convenience in the field.
From a design perspective, the Weidmüller 1002090000 PCB female plug connector is a practical choice where a reliable pluggable interface is needed without moving to a larger terminal format. It supports clean board integration while keeping the connection accessible for technicians.
FAQ: Weidmüller 1002090000 PCB Plug Connector
What is the Weidmüller 1002090000?
The Weidmüller 1002090000 is a 2-pole PCB plug connector with a female plug design, 5.08 mm pitch, and a PUSH IN connection with actuator.
What is the pitch of the Weidmüller 1002090000 connector?
The pitch is 5.08 mm, which is a common format in industrial pluggable PCB connection systems.
What are the voltage and current ratings?
The connector is rated at 400 V / 24 A under IEC and 300 V / 18.5 A under UL, depending on installation conditions.
What wire sizes can be used?
It supports 0.2 to 2.5 mm² conductors under IEC and AWG 26 to AWG 12 under UL.
Why choose a PUSH IN PCB plug connector?
PUSH IN technology simplifies conductor insertion, supports efficient wiring, and is well suited to modern industrial assembly and maintenance workflows.
Where is the Weidmüller 1002090000 commonly used?
It is commonly used in compact industrial boards, signal modules, building automation electronics, and machine-related control assemblies.
For more information about Weidmüller, review the wider portfolio of PCB connection products.
