Weidmüller 1002000000 PCB Terminal Block: What Engineers Need to Know
The Weidmüller 1002000000 PCB terminal block, identified as Weidmüller LL 5.08/19/90 3.2SN OR BX PCB terminal block, is intended for industrial wire termination directly on the printed circuit board. In applications that demand structured wiring, dependable clamping, and long-term serviceability, this kind of terminal remains one of the most practical connection formats available.
With 19 poles, this version gives designers more flexibility than common mid-range pole counts, especially on custom automation boards or control modules where signal concentration is moderately high. It belongs to the OMNIMATE Signal LL family and follows the same general platform features: 5.08 mm pitch, 90° outlet direction, THT mounting, and a 3.2 mm tinned solder pin.
Technical Characteristics of Weidmüller 1002000000
The Weidmüller 1002000000 printed circuit board terminal uses a clamping yoke connection and supports conductor sizes up to 6 mm². Published technical data for the LL 5.08/90 family lists an IEC rating of 500 V / 32.5 A with a conductor range of 0.5 to 6 mm², and a UL rating of 300 V / 20 A for AWG 26 to AWG 12 conductors.
The terminal is supplied in orange, which is widely recognized in industrial electrical assemblies and can support quick visual identification. In many projects, component color is more than an aesthetic detail; it can contribute to maintenance clarity and assembly consistency.
Why a 19-Pole Terminal Can Be Useful
A 19-pole PCB terminal block is particularly relevant in applications where one additional pole can eliminate the need for splitting a connection group across two terminal sections. That sounds minor at first, but in PCB design, avoiding unnecessary segmentation often improves layout simplicity, reduces labeling confusion, and supports cleaner wiring diagrams.
The Weidmüller 1002000000 wire-to-board terminal block can therefore be valuable in industrial controllers, interface units, metering boards, and process electronics that handle grouped channels or combined field signals. Its right-angle wire orientation also helps when the enclosure or device housing has limited vertical clearance.
Application Areas in Industrial Electronics
This terminal block is appropriate for machine control boards, test and measurement systems, HVAC electronics, building automation devices, industrial safety interfaces, and custom panel-integrated electronics. These are all environments where the practical realities of commissioning and servicing matter. A good PCB terminal block must be easy to understand in the field, not just easy to place in CAD.
Relevant search phrases around this product typically include Weidmüller 1002000000 PCB terminal block, Weidmüller 1002000000 terminal block, 19 pole PCB terminal block, and industrial 5.08 mm terminal block. These keyword patterns reflect how engineers look for components by function, spacing, brand, and exact order code.
Board-Level Implementation Advice
As with any industrial PCB terminal, performance depends on the complete assembly. Designers should verify trace geometry, spacing, current distribution, and expected ambient temperature. The nominal values associated with the Weidmüller LL 5.08/19/90 3.2SN OR BX PCB terminal block are only one part of the design equation.
It is also beneficial to consider accessibility during future maintenance. Clear numbering, sensible signal grouping, and enough space for conductor insertion and screw access can significantly improve usability over the product lifecycle.
FAQ: Weidmüller 1002000000 PCB Terminal Block
What is the Weidmüller 1002000000?
The Weidmüller 1002000000 is a 19-pole PCB terminal block from the OMNIMATE Signal LL series, designed for direct wire-to-board connections.
What kind of connection does it use?
It uses a clamping yoke screw connection, a common industrial terminal technology chosen for secure conductor clamping and practical maintenance access.
What pitch does the Weidmüller 1002000000 use?
The pitch is 5.08 mm, making it suitable for many established industrial board layouts and replacement requirements.
What are the main electrical ratings?
The LL 5.08/90 family is published with IEC 500 V / 32.5 A and UL 300 V / 20 A ratings, with conductor support up to 6 mm² or AWG 12 depending on standard and installation conditions.
What type of PCB mounting does it require?
This is a through-hole terminal block with a 3.2 mm tinned solder pin, intended for THT solder connection to the PCB.
Where is the Weidmüller 1002000000 commonly used?
It is commonly relevant for industrial control systems, interface boards, machine electronics, instrumentation modules, and building automation products that need reliable PCB wiring.
