Weidmüller 1001630000 BLF 5.08HC/12/90 Female Plug Overview
The Weidmüller 1001630000 BLF 5.08HC/12/90 female plug is intended for PCB systems that need a broad pluggable wiring interface while preserving the robust usability associated with 5.08 mm pitch connectors. In many industrial and infrastructure products, a 12-pole connector allows designers to handle a full subsystem connection in one compact, removable interface. That is a major advantage when modularity and service access are part of the product strategy.
According to the product data, this is a female PCB plug-in connector with 5.08 mm pitch, 12 poles, 90° entry, and PUSH IN with actuator technology. It supports a clamping range up to 3.31 mm² and is listed with IEC 400 V / 24 A / 0.2–2.5 mm² and UL 300 V / 18.5 A / AWG 26–12.
What Kind of Product Is Weidmüller 1001630000?
The Weidmüller BLF 5.08HC/12/90 female plug is the detachable cable-side part of a PCB pluggable connection system. It is designed to mate with an appropriate board header and provide a structured, service-friendly connection point for a high number of conductors.
This matters in products where the wiring side must remain organized and detachable. In service scenarios, being able to separate the board from the field wiring without re-terminating each conductor is a major advantage.
Why 12 Poles Can Improve Product Architecture
A Weidmüller 1001630000 12-pole connector can handle more sophisticated grouped interfaces such as control and feedback bundles, power and signal combinations, multi-channel device links, or standardized machine subassembly connections. Instead of distributing these across multiple smaller connectors, designers can use one structured interface.
This often improves board-edge efficiency, labeling clarity, and service logic. The end result is not only technically effective but also easier for installers and technicians to work with.
5.08 mm Pitch in Higher Pole Counts
The Weidmüller BLF 5.08HC/12/90 5.08 mm female plug demonstrates why this pitch remains so valuable. Even with a higher number of poles, it still offers practical conductor spacing and manageable handling. Smaller pitch systems may save some space, but they can become much less comfortable during installation and maintenance when the pole count grows.
That is why many industrial products continue to rely on 5.08 mm systems for structured and user-friendly pluggable connectivity.
90° Wire Entry and PUSH IN Efficiency
The right-angle entry of the Weidmüller 1001630000 BLF 5.08HC/12/90 SN OR BX supports side cable routing, which is a major benefit in compact electronics housings. It helps keep the wiring path controlled and can reduce congestion near the connector face.
PUSH IN with actuator technology adds operational value by enabling faster and more intuitive conductor insertion. In both serial production and field maintenance, this can improve workflow and reduce the risk of wiring mistakes.
Where This Connector Is Commonly Used
The Weidmüller 1001630000 female plug is suitable for controller interfaces, automation platforms, machine subassemblies, energy and building systems, and compact industrial electronics that require a 12-pole pluggable connection interface.
For Weidmüller solutions, it is worth reviewing compatible headers and the broader product family to build a consistent board connection architecture.
FAQ
What is Weidmüller 1001630000?
It is a 12-pole female PCB plug-in connector with 5.08 mm pitch and 90-degree cable entry.
Why choose a 12-pole connector?
It allows larger grouped interfaces to be handled in a single connector body, which can simplify layout and improve serviceability.
What ratings are listed for this product?
The product data lists IEC 400 V / 24 A / 0.2–2.5 mm² and UL 300 V / 18.5 A / AWG 26–12.
What connection technology is used?
It uses PUSH IN with actuator technology for quick and practical conductor insertion.
Why is 90-degree wire entry important?
It supports cleaner side cable routing and better space management in compact enclosures.
What applications suit this connector?
It suits controller boards, automation systems, machine modules, and modular PCB platforms with higher conductor counts.
