Weidmüller 1001580000 BLF 5.08HC/07/90 Female Plug Guide
The Weidmüller 1001580000 BLF 5.08HC/07/90 female plug is a versatile PCB connector for applications where seven connection points need to be grouped in one reliable, service-friendly interface. In industrial electronics, that pole count often works extremely well for mixed signal and control layouts, especially when designers want to keep the wiring organized without stepping up to much larger connection systems.
According to the product data, this is a female PCB plug-in connector with 5.08 mm pitch, 7 poles, 90° cable entry, and PUSH IN with actuator technology. The listed clamping range goes up to 3.31 mm², with product data showing IEC 400 V / 24 A / 0.2–2.5 mm² and UL 300 V / 18.5 A / AWG 26–12.
Why the Weidmüller 1001580000 Connector Matters
The Weidmüller BLF 5.08HC/07/90 female plug is a strong example of how pluggable PCB connectivity can improve both installation and maintenance. Instead of terminating every conductor directly on the PCB side in a way that complicates board replacement, the plug-and-header concept allows wiring to remain grouped and detachable. That is especially valuable in products that may need servicing in the field.
Seven poles is a particularly practical configuration for compact controller interfaces, sensor hubs, signal routing boards, smart building devices, and machine subassemblies. It provides more room for grouped functions than smaller versions while preserving the efficient handling that makes the BLF family attractive.
Technical Value of the 7-Pole Version
A Weidmüller 1001580000 7-pole female plug can support a wide variety of grouped connection requirements. In real projects, seven poles may be used for multi-channel control, combined signal and auxiliary power lines, actuator groups, or structured interface tasks. This makes the product highly adaptable in modular electronics.
At the same time, because it remains within the 5.08 mm pitch platform, it preserves comfortable conductor access and a familiar physical scale. Engineers often prefer this because it strikes a balance between density and usability. The board stays compact, but the connector still feels substantial enough for confident field wiring.
How 90° Entry Helps in Product Design
The Weidmüller BLF 5.08HC/07/90 90-degree female plug supports lateral conductor routing. This is useful in compact enclosures, DIN-rail electronics, and panel-mounted systems where side cable guidance makes the internal layout more efficient. Instead of creating a wiring path that projects outward and consumes more space, the connector helps direct conductors into a more controlled side-oriented path.
That can reduce clutter, improve visual order, and make maintenance easier when several connectors are mounted close together.
PUSH IN with Actuator as a Practical Advantage
The Weidmüller 1001580000 BLF 5.08HC/07/90 SN OR BX uses PUSH IN with actuator connection technology, which is widely valued for quick operation and dependable conductor handling. In large production runs or field installations, connection technology that reduces wiring effort without compromising security has a clear operational advantage.
For many engineers, that makes this product attractive not only from a technical standpoint but also from a process standpoint. The connector contributes to faster assembly and a more user-friendly service experience.
Typical Application Areas
The Weidmüller 1001580000 female plug can be applied in industrial controls, compact machine electronics, relay and interface boards, building automation modules, and modular embedded systems where seven grouped conductors need to be connected through a pluggable PCB interface.
For more information, matching Weidmüller headers and related connectivity products in the same platform are worth reviewing to create a fully compatible connection concept.
Weidmüller 1001580000 FAQ
What is Weidmüller 1001580000?
It is a 7-pole female PCB plug-in connector with 5.08 mm pitch and 90-degree wire entry.
What makes 7 poles useful?
Seven poles can support more complex grouped wiring tasks while still keeping the connector compact and practical for PCB use.
Does this connector use spring technology?
Yes. It uses PUSH IN with actuator connection technology for intuitive and secure conductor insertion.
What are the rated values?
The product data lists IEC 400 V / 24 A / 0.2–2.5 mm² and UL 300 V / 18.5 A / AWG 26–12.
Why is 90-degree wire entry preferred in many enclosures?
Because it supports side cable routing, helps save space, and improves internal wire organization.
Where can this connector be used?
It is suitable for controller boards, automation electronics, interface modules, and smart device assemblies that benefit from pluggable wiring.
