Weidmüller 1001570000 BLF 5.08HC/06/90 Female Plug Overview
The Weidmüller 1001570000 BLF 5.08HC/06/90 female plug is designed for PCB connection projects that need a balanced mix of wiring comfort, modularity, and reliable board interfacing. In industrial electronics, connectors in the six-pole range are often selected because they can support more complex circuit grouping without forcing designers into oversized connection hardware. That makes this model highly practical in real engineering work.
The product is listed as a female PCB plug-in connector with 5.08 mm pitch, 6 poles, 90° entry, and PUSH IN with actuator technology. It also supports a clamping range up to 3.31 mm², with product data showing IEC 400 V / 24 A / 0.2–2.5 mm² and UL 300 V / 18.5 A / AWG 26–12.
What Makes Weidmüller 1001570000 Relevant?
The Weidmüller 1001570000 BLF 5.08HC/06/90 connector gives design teams a pluggable six-pole interface that is compact enough for modern PCB layouts while still offering the conductor space and handling comfort associated with 5.08 mm pitch systems. In serviceable devices, this matters because it allows the field wiring side to remain intact while the PCB side can be disconnected as needed.
This kind of modularity is extremely useful in building control units, machine electronics, energy management boards, small drive systems, interface modules, and signal distribution assemblies. The connector becomes part of a smarter maintenance workflow rather than just a static connection point.
Technical Strength of the 6-Pole Layout
A Weidmüller BLF 5.08HC/06/90 female plug is often ideal for grouped wiring tasks where five poles are just slightly too limited and larger connector bodies would consume unnecessary space. Six poles can support multi-signal interfaces, paired power and control circuits, relay output groups, and compact field wiring clusters. That flexibility is one of the strongest arguments in favor of this exact configuration.
Because the connector remains within the 5.08 mm family, it also fits easily into well-established industrial design habits. Engineers, panel builders, and service teams are already familiar with this pitch, which makes it easier to specify, install, and maintain.
Benefits of Right-Angle Cable Entry
The Weidmüller 1001570000 90-degree female plug directs the wires sideways rather than straight forward. This can improve internal cable organization in narrow housings and cabinet-mounted equipment. In many practical installations, side-directed wire entry reduces conductor congestion near the connector and helps maintain a cleaner visual and mechanical layout.
Right-angle entry is particularly useful when the PCB is positioned parallel to an enclosure wall or when multiple connectors must be arranged in a row with efficient side cable routing.
PUSH IN Connection in Daily Use
One of the most useful features of the Weidmüller BLF 5.08HC/06/90 SN OR BX is its PUSH IN with actuator technology. This style of connection is appreciated because it supports fast conductor insertion and reliable clamping while keeping operation intuitive. In manufacturing and field wiring alike, ease of use translates into fewer handling mistakes and more consistent results.
For products that will be wired frequently or installed in volume, this is more than a convenience feature. It becomes an efficiency factor across the entire product lifecycle.
Where This Connector Fits Best
The Weidmüller 1001570000 female plug is well suited to industrial control boards, smart building devices, compact automation products, distributed I/O modules, and any PCB-based system that benefits from a 6-pole pluggable wiring interface. It supports structured wiring, simplified maintenance, and a solid conductor handling experience.
Weidmüller 1001570000 For Weidmüller product families, pairing this connector with the right board-mounted header is the key to achieving a clean and durable pluggable connection strategy.
Weidmüller 1001570000 FAQ
What is Weidmüller 1001570000 used for?
It is used as a 6-pole female plug in a pluggable PCB connection system for industrial and electronic applications.
Why choose a 6-pole connector?
A 6-pole connector provides extra flexibility for grouped wiring while still staying compact enough for efficient board layouts.
What pitch does this product use?
It uses a 5.08 mm pitch, which is one of the most common dimensions in industrial PCB connectivity.
What are the electrical ratings?
The product data lists IEC 400 V / 24 A / 0.2–2.5 mm² and UL 300 V / 18.5 A / AWG 26–12.
Why is 90-degree wire entry useful?
It improves side cable routing, helps save internal space, and supports cleaner wiring paths in many enclosure layouts.
What kind of connection system does it use?
It uses PUSH IN with actuator technology for quick, intuitive, and secure conductor insertion.
