Weidmüller 1001210000 BLDF 5.08/08/180 SN OR BX Technical Overview
The Weidmüller 1001210000 BLDF 5.08/08/180 SN OR BX is an 8-pole PCB plug-in connector intended for industrial systems that require multiple conductors in a single reliable board connection point. In machine building, industrial automation, and control electronics, 8-pole connectors are often selected when designers want to reduce connector count and keep grouped functions together. The Weidmüller 1001210000 PCB connector supports that goal with a widely used industrial format and practical connection technology.
Product Concept and Industrial Relevance
This connector is part of the OMNIMATE Signal family and is designed as a female plug for pluggable PCB connections. The pluggable concept provides a clear maintenance advantage because it allows the wired section to be disconnected from the board-side header when required. That helps with replacement, diagnostics, and modular assembly. In industrial practice, such serviceability can be just as important as the raw electrical data.
Technical Characteristics
The Weidmüller 1001210000 BLDF 5.08/08/180 SN OR BX has 8 poles and uses a 5.08 mm pitch. It features a 180° conductor outlet and PUSH IN with actuator technology. The official product data lists a conductor range of 0.2 to 2.5 mm² and a maximum clamping range of 3.31 mm². Electrical values are given as 400 V and 20.8 A under IEC, and 300 V and 18.5 A under UL. These values make the connector suitable for serious industrial board wiring rather than only light-duty applications.
Why 8 Poles Can Simplify Design
Using an 8-pole PCB plug-in connector can reduce the need for multiple smaller connectors, which in turn may simplify labeling, layout logic, and assembly planning. The Weidmüller 1001210000 is particularly useful where designers want a clean, grouped connection point for multiple signals or mixed functional lines. That can improve both visual clarity and service efficiency.
Advantages of the 180° Outlet and PUSH IN System
The straight 180° conductor outlet helps keep routing predictable inside devices and panels. This is especially helpful in compact housings or modules where wire direction strongly affects layout quality. At the same time, PUSH IN with actuator technology supports fast installation and dependable conductor holding. Together, these design choices make the Weidmüller 1001210000 BLDF 5.08/08/180 SN OR BX a practical connector for real industrial workflows.
Application Areas
This connector is suitable for controller modules, industrial interface boards, automation devices, compact machine electronics, instrumentation systems, and OEM product lines that benefit from modular pluggable connectivity. Because it uses a familiar 5.08 mm pitch, it also fits easily into many established design practices and component ecosystems.
For more information about Weidmüller, reviewing compatible headers and neighboring variants in the same family can support better platform standardization.
FAQ
What is the Weidmüller 1001210000?
It is an 8-pole PCB plug-in connector in a female plug format.
What pitch is used by this connector?
The connector uses a 5.08 mm pitch.
How many poles does the Weidmüller 1001210000 BLDF 5.08/08/180 SN OR BX have?
It has 8 poles.
What conductor sizes are supported?
The official product data lists a conductor range of 0.2 to 2.5 mm².
What electrical ratings are listed?
The connector is listed at 400 V and 20.8 A under IEC, and 300 V and 18.5 A under UL.
What is the advantage of an 8-pole connector?
It allows more channels to be grouped in one connection point, which can simplify layout and reduce connector count.
Why is the 180° outlet useful?
It helps keep wire routing straight and more manageable inside the device or enclosure.
Where is this product commonly used?
It is commonly used in industrial control electronics, automation devices, interface boards, and machine-related PCB assemblies.
