Weidmüller 1001200000 BLDF 5.08/07/180 SN OR BX Connector Guide
The Weidmüller 1001200000 BLDF 5.08/07/180 SN OR BX is a 7-pole PCB plug-in connector built for industrial applications that require reliable board-level field wiring and an efficient, maintainable connection concept. Seven poles are often chosen when a design needs more than a standard 6-pole arrangement but should remain narrower than an 8-pole alternative where possible. That gives the Weidmüller 1001200000 PCB connector a very practical role in control electronics and modular automation systems.
What This Connector Offers
The product belongs to the OMNIMATE Signal family and is configured as a female plug. Its pluggable structure helps engineers and service teams work more efficiently by separating the wired plug from the board-side header. This can improve production workflows, simplify replacement procedures, and reduce downtime during maintenance. In many industrial products, that is a clear operational advantage.
Technical Data of the Weidmüller 1001200000
The Weidmüller 1001200000 BLDF 5.08/07/180 SN OR BX has a 5.08 mm pitch and 7 poles. It uses a 180° conductor outlet and PUSH IN with actuator technology. The listed conductor range is 0.2 to 2.5 mm², and the maximum clamping range is 3.31 mm². Official product information states IEC values of 400 V and 20.8 A, while UL values are given as 300 V and 18.5 A. Those values make the connector appropriate for a wide range of industrial control and interface tasks.
Why a 7-Pole Format Can Be the Best Fit
Engineering efficiency often comes down to choosing the right format rather than the biggest one. A 7-pole connector gives designers one extra position beyond a 6-pole layout while staying more tailored than jumping directly to 8 poles. The Weidmüller 1001200000 supports that kind of precise application matching, which is especially useful in compact industrial boards where every millimeter counts.
Handling and Wiring Advantages
The 5.08 mm pitch is widely trusted in industrial PCB connectivity because it is easy to handle and well suited to robust wiring tasks. Combined with PUSH IN with actuator technology, the Weidmüller 1001200000 supports efficient conductor insertion and reliable connection quality. The straight 180° conductor outlet further contributes to neat internal cable routing, which can improve serviceability and help keep enclosure layouts under control.
Application Areas
The Weidmüller 1001200000 BLDF 5.08/07/180 SN OR BX is suitable for compact automation devices, machine interface boards, industrial control modules, monitoring electronics, and PCB assemblies that require a 7-pole pluggable connection point. Its orange housing can support visual organization where multiple connector groups exist within the same system.
For more information about Weidmüller, comparing adjacent pole counts in the same series can help maintain a consistent connector strategy across related products.
FAQ
What is the Weidmüller 1001200000?
It is a 7-pole PCB plug-in connector in a female plug format.
What pitch does this connector use?
It uses a 5.08 mm pitch.
How many poles does the Weidmüller 1001200000 BLDF 5.08/07/180 SN OR BX have?
It has 7 poles.
What connection technology is used?
It uses PUSH IN with actuator technology.
What conductor range is supported?
The product data lists a conductor range of 0.2 to 2.5 mm².
What electrical ratings are listed?
The listed values are 400 V and 20.8 A under IEC, and 300 V and 18.5 A under UL.
Why choose a 7-pole connector instead of 6 or 8 poles?
It can match the exact application requirement more closely and help optimize PCB space and wiring layout.
Where is this connector typically used?
It is typically used in industrial control boards, interface electronics, automation modules, and machine-related PCB assemblies.
