Weidmüller 1001160000 BLDF 5.08/03/180 SN OR BX PCB Connector Guide
The Weidmüller 1001160000 BLDF 5.08/03/180 SN OR BX is a 3-pole PCB plug-in connector built for industrial field wiring on printed circuit boards. In many automation and control applications, a 3-pole connector is exactly the right format. It offers enough positions for compact power, signal, and functional interfaces without taking more board space than necessary. That makes the Weidmüller 1001160000 PCB plug-in connector a practical choice in systems where clean design and maintainable wiring are equally important.
What This Connector Is Designed To Do
The Weidmüller 1001160000 belongs to the OMNIMATE Signal range and is designed as a female plug for pluggable PCB connection. This product concept is useful wherever engineers want the flexibility to separate the wired plug from the board-side header during assembly, maintenance, or replacement. Instead of treating the entire wiring point as fixed, a pluggable connector architecture supports modular service and a more organized installation process.
Technical Profile of the Weidmüller 1001160000
The Weidmüller 1001160000 BLDF 5.08/03/180 SN OR BX uses a 5.08 mm pitch and provides 3 poles. It features a 180° conductor outlet and uses PUSH IN with actuator technology. The listed conductor range is 0.2 to 2.5 mm², while the maximum clamping range is 3.31 mm². The official product data lists IEC values of 400 V and 20.8 A and UL values of 300 V and 18.5 A. These figures position the connector well for practical industrial use, especially in control electronics and compact device interfaces.
Why a 3-Pole PCB Plug-In Connector Is Useful
In design work, a 3-pole connector is often selected for compact applications such as line, neutral, and protective conductor arrangements, grouped control lines, or sensor-related signal interfaces. Using the correct pole count matters because it helps avoid wasted board space and keeps the layout easy to understand. The Weidmüller 1001160000 connector provides that efficiency while still retaining the core benefits of an industrial pluggable system.
The 5.08 mm pitch also remains highly relevant because it is familiar, easy to handle, and well suited to board-level industrial wiring. Engineers continue to search for 5.08 mm PCB connectors because this pitch balances electrical performance, physical accessibility, and layout efficiency.
PUSH IN Connection Advantages
The PUSH IN with actuator system is one of the strongest aspects of the Weidmüller 1001160000 BLDF 5.08/03/180 SN OR BX. In manufacturing, it helps speed up wiring. In service, it supports repeatable and secure conductor handling. In industrial equipment exposed to vibration and long operating cycles, stable contact quality becomes essential, and spring-based connection technology remains attractive for that reason.
Typical Applications
This Weidmüller 1001160000 PCB connector is well suited to compact control boards, industrial interface boards, low-channel automation devices, instrumentation electronics, and machine-mounted modules. Its orange housing can also support visual identification inside a mixed wiring environment. Where engineers need a compact 3-pole pluggable connector with dependable ratings and straightforward handling, this model is an effective option.
For more information about Weidmüller, comparing related BLDF variants can help define a more consistent connector strategy across multiple board designs.
FAQ
What product type is the Weidmüller 1001160000?
It is a PCB plug-in connector in a female plug format for industrial board-level field wiring.
How many poles does the Weidmüller 1001160000 have?
This model has 3 poles.
What is the pitch of the connector?
The connector uses a 5.08 mm pitch.
What connection technology does it use?
It uses PUSH IN with actuator technology for efficient and secure conductor connection.
What conductor sizes are supported?
The listed conductor range is 0.2 to 2.5 mm².
What are the electrical ratings?
The product data lists IEC values of 400 V and 20.8 A and UL values of 300 V and 18.5 A.
Why is a 3-pole connector useful on a PCB?
It is ideal for compact functional groups where three connection points are enough and unnecessary connector width should be avoided.
Where is this connector commonly used?
It is commonly used on control boards, industrial interface electronics, small automation modules, and instrumentation devices.
