Weidmüller 1001050000 BLDF 5.08/06/180LR SN BK BX PCB Plug-In Connector Guide
The Weidmüller 1001050000 BLDF 5.08/06/180LR SN BK BX is a PCB plug-in connector designed for structured, reliable field wiring in control electronics, interface boards, and industrial assemblies. In practical terms, this model brings together a 5.08 mm pitch, a 6-pole layout, and a 180° conductor outlet in a format that suits compact yet serviceable connection designs. Engineers who work with industrial PCB terminal blocks often look for a connector that balances current handling, easy installation, and dependable contact stability. This is exactly where the Weidmüller 1001050000 PCB plug-in connector fits in.
What the Weidmüller 1001050000 Is Designed For
This connector belongs to the OMNIMATE Signal family and is intended for field connection on PCBs. The female plug format makes it appropriate for pluggable architectures where fast replacement, maintenance access, or modular assembly is important. Instead of hardwiring every conductor directly to the board, the pluggable concept allows installers and service teams to separate the wiring side from the PCB side when needed. That is a practical advantage in machine building, building automation panels, power electronics, HVAC control boards, and general industrial control applications.
Key Technical Characteristics
The Weidmüller 1001050000 BLDF 5.08/06/180LR SN BK BX uses a 5.08 mm pitch and offers 6 poles, making it suitable for circuits that need several signals or combined signal-and-power paths in one compact connector body. It uses PUSH IN with actuator technology, which is widely appreciated in modern industrial wiring because it supports quick conductor termination and a secure, vibration-resistant contact. The rated connection cross-section is 0.2 to 2.5 mm², and the maximum clamping range is 3.31 mm². For many control cabinet and device-level wiring tasks, that range covers the conductors most commonly used in practice.
From an electrical standpoint, this Weidmüller 1001050000 connector is specified at up to 400 V and 20.8 A under IEC data, with UL data listed at 300 V and 18.5 A. The 180° cable outlet supports straight conductor routing, which can simplify internal layout planning on assemblies where wiring needs to run parallel to the board or enclosure structure.
Why the 5.08 mm Pitch Still Matters
Search demand around terms like PCB terminal block, pluggable terminal block, and 5.08 mm PCB connector remains consistently strong because this pitch is one of the most familiar standards in industrial electronics. A 5.08 mm pitch gives designers a useful balance: it is compact enough for board efficiency, yet spacious enough for practical handling, insulation distances, and robust conductor insertion. In the case of the Weidmüller 1001050000 BLDF 5.08/06/180LR SN BK BX, that balance makes the connector especially relevant in applications where maintainability matters just as much as board density.
Installation and Handling Advantages
One of the most useful aspects of this Weidmüller 1001050000 PCB plug-in connector is the PUSH IN with actuator system. In the field, installers benefit from quick wire connection and a repeatable contact interface. The design also supports dependable retention and stable performance under vibration, which is important in industrial cabinets, machine frames, and transport-related equipment. The connector is touch-safe by design, which contributes to a safer maintenance environment when the overall assembly is designed correctly.
For panel builders and OEM engineers, another important point is serviceability. A pluggable connector architecture can reduce service downtime because the wired plug section can often be removed and reconnected more efficiently than a fully fixed connection method.
Typical Use Cases
The Weidmüller 1001050000 BLDF 5.08/06/180LR SN BK BX is a strong fit for PLC-related I/O boards, control modules, signal distribution boards, interface electronics, sensor integration boards, and compact industrial devices. A 6-pole arrangement is often selected when designers need a manageable number of conductors without stepping up to a larger connector body than necessary. In many applications, that means cleaner layouts and easier routing.
For more information about Weidmüller, it helps to review the broader connector family and compare mating concepts, pole counts, and wiring formats before finalizing a design.
FAQ
What product type is the Weidmüller 1001050000?
The Weidmüller 1001050000 is a PCB plug-in connector in a female plug format intended for field wiring on printed circuit boards.
How many poles does the Weidmüller 1001050000 BLDF 5.08/06/180LR SN BK BX have?
This model has 6 poles, which makes it suitable for multi-conductor signal or combined signal-and-power connections in industrial devices.
What is the pitch of the Weidmüller 1001050000 PCB connector?
The connector uses a 5.08 mm pitch, a widely used spacing in industrial PCB terminal block and pluggable connector designs.
What wire sizes are suitable for this connector?
The rated conductor range is 0.2 to 2.5 mm², covering many common industrial wiring sizes used in control and interface applications.
What does the 180° conductor outlet mean in practice?
It means the conductors exit in a straight orientation relative to the connector body, which can support clean cable routing and predictable enclosure layout.
Is the Weidmüller 1001050000 suitable for industrial environments?
Yes. Its design emphasizes secure contact performance, vibration resistance, and efficient field wiring, all of which are relevant in industrial use.
Why do engineers choose a pluggable PCB connector instead of a fixed terminal?
A pluggable connector can simplify assembly, maintenance, and replacement work. It also supports modular product design and faster service access.
What makes this Weidmüller 1001050000 connector attractive for control boards?
Its combination of 6 poles, 5.08 mm pitch, PUSH IN technology, and practical current and voltage ratings makes it a useful option for control electronics and interface boards.
