Weidmüller 1001040000 BLDF 5.08/05/180LR SN BK BX: Technical Overview of a 5-Pole PCB Female Plug
The Weidmüller 1001040000 BLDF 5.08/05/180LR SN BK BX is a five-pole pluggable connector designed for industrial wire-to-board connections. It belongs to the OMNIMATE Signal connector range, a series known for combining reliable electrical contact with easy installation and long-term serviceability.
Connector Architecture
This Weidmüller BLDF 5.08/05/180LR SN BK BX uses a 5.08 mm pitch and a straight 180-degree conductor outlet. The connector supports PUSH IN with actuator wiring technology, allowing technicians to insert conductors quickly while maintaining secure contact pressure.
Five-pole connectors are often selected for applications requiring multiple signals or combined power and control connections. The configuration allows engineers to keep PCB layouts efficient while maintaining organized wiring.
Advantages of the BLDF Connector System
The BLDF series is designed to provide practical advantages during installation and maintenance. The removable wire-side plug enables technicians to disconnect wiring harnesses easily when replacing modules or servicing equipment.
The Weidmüller 1001040000 female PCB plug also benefits from the robust mechanical design typical of the OMNIMATE connector family. The housing provides reliable insulation while ensuring proper conductor alignment and retention.
Industrial Applications
The connector is widely used in industrial control systems, building automation equipment, and machine interface electronics. Its compact size and five-position layout make it suitable for:
- Automation control modules
- Relay interface boards
- Monitoring devices
- Industrial sensor systems
- Embedded controller hardware
Search queries for this product often include Weidmüller 1001040000, BLDF 5.08/05/180LR SN BK BX, and Weidmüller 5-pole PCB plug.
FAQ
What type of connector is Weidmüller 1001040000?
It is a female plug for pluggable PCB wire-to-board connections.
How many poles does it have?
The connector includes five connection positions.
What pitch does it use?
The pitch is 5.08 mm.
What wiring technology is used?
It uses PUSH IN with actuator technology.
Why is a pluggable PCB connector useful?
It simplifies installation and maintenance by allowing wiring to be disconnected quickly.
Where is this connector typically applied?
It is commonly used in automation electronics and industrial control equipment.
For more about Weidmüller, exploring the OMNIMATE product line can help identify compatible headers and accessories.
